IORE..AME contactors
Power circuit up to 500 V AC, with mechanical latching
DC operated

Description
IORE..-AME contactors are used for controlling AC power circuits up to 500 V AC.

1SBC104044F0000 These contactors are designed with: 3
–– mechanical latching
–– variable number of poles according to the application
–– control circuit: DC operated
–– 1 N.O. and 1 N.C. auxiliary contacts available.

Ordering details

IORE800-30-AME AC-3 AC-1 Nb of Rated control Auxiliary Type Order code Weight

Rated operational poles circuit voltage contacts Pkg
fitted (2) (1 pce)
power current Uc
(1)
380 V 440 V 500 V ≤ 440 V θ ≤ 40 °C
400 V

415 V

kW kW kW A A V DC kg

450 500 560 800 900 2 220 1 1 IORE800-20-AME FPL8619225R0116 48
1 1 IORE800-30-AME FPL8619325R0116 58
3 1 1 IORE800-40-AME FPL8619425R0116 68
48
4 220 1 1 IORE1000-20-AME FPL8719225R0116 58
1 1 IORE1000-30-AME FPL8719325R0116 68
---- 1000 2 1 1 IORE1000-40-AME FPL8719425R0116 50
60
3 220 1 1 IORE1400-20-AME FPL6119225R0116 73
1 1 IORE1400-30-AME FPL6119325R0116 54
4 1 1 IORE1400-40-AME FPL6119425R0116 66
82
630 710 800 1080 1350 2 220 1 1 IORE1700-20-AME FPL6219225R0116 58
1 1 IORE1700-30-AME FPL6219325R0116 72
3 1 1 IORE1700-40-AME FPL6219425R0116 88
On
4 220 1 1 IORE2100-20-AME FPL6319225R0116 request
1 1 IORE2100-30-AME FPL6319325R0116
750 800 900 1260 1650 2 1 1 IORE2100-40-AME FPL6319425R0116 On
request
3 220 1 1 IORE2500-20-AME FPL6719225R0116
1 1 IORE2500-30-AME FPL6719325R0116 On
4 request
220 1 1 IORE3200-20-AME FPL6519225R0116
900 1000 1000 1520 2000 2 1 1 IORE3200-30-AME FPL6519325R0116 On
request
3 220 1 1 IORE3800-20-AME FPL6619225R0116

4

---- 2400 2

3

---- 3200 2

3

---- 3800 2

---- 4500 2 220 1 1 IORE4500-20-AME FPL6819225R0116

(1) Other control voltages see voltage code table.
(2) Other auxiliary contact arrangements, see auxiliary contact code table.
