IORR..CC-AMA and IORR..CC-AME contactors
Power circuit up to 1500 V DC, with latching
AC operated

1SBC104044F0000 Description

IORR800-30-CC-AME IORR..CC-AMA and IORR..CC-AME contactors are used for controlling DC power circuits up to 1500 V DC.

4 These contactors are designed with:
–– magnetical latching, AMA types
–– mechanical latching, AME types
–– variable number of poles according to the application
–– control circuit: AC operated
–– 1 N.O. auxiliary contact available for AMA version, as standard
–– 1 N.O. and 1 N.C. auxiliary contacts available for AME version.

Ordering details

IEC Number Rated con- Auxiliary Type Order code Weight
of poles trol circuit
DC-1 DC-3 / DC-5 voltage contacts pkg
Rated operationnal Rated operationnal Uc fitted (2) (1 pce)
(1)
current voltage current voltage kg
V 50/60 Hz
(3) (3)

A V DC A V DC

Magnetical latching

85 500 68 500 1 220...230 1 0 IORR63-10-CC-AMA FPL7116136R0006 2.9
1000 2 1 0 IORR63-20-CC-AMA FPL7116236R0006 3.9
1000 1500 3 1 0 IORR63-30-CC-AMA On request 4.9
500 1 220...230 1 0 IORR125-10-CC-AMA FPL7416135R0006 3.9
1500 1000 2 1 0 IORR125-20-CC-AMA FPL7416235R0006 5.9
1500 3 1 0 IORR125-30-CC-AMA On request 7.9
170 500 125 500 1 220...230 1 0 IORR200-10-CC-AMA FPL7616135R0006 6.2
1000 2 1 0 IORR200-20-CC-AMA FPL7616235R0006 9.2
1000 1500 3 1 0 IORR200-30-CC-AMA On request 12.2

1500

275 500 205

1000

1500

Mechanical latching

400 500 350 500 1 220...230 1 1 IORR400-10-CC-AME FPL9416125R0116 18.4
1000 2 1 1 IORR400-20-CC-AME FPL9416225R0116 24.2
1000 1500 3 1 1 IORR400-30-CC-AME On request 30
500 1 220...230 1 1 IORR500-10-CC-AME FPL8316125R0116 18.4
1500 1000 2 1 1 IORR500-20-CC-AME FPL8316225R0116 24.2
1500 3 1 1 IORR500-30-CC-AME On request 30
550 500 500 600 1 220...230 1 1 IORR800-10-CC-AME FPL8616125R0116 40
1000 2 1 1 IORR800-20-CC-AME FPL8616225R0116 50
1000 1500 3 1 1 IORR800-30-CC-AME FPL8616325R0116 61
600 1 220...230 1 1 IORR1000-10-CC-AME FPL8716125R0116 40
1500 1000 2 1 1 IORR1000-20-CC-AME FPL8716225R0116 50
1500 3 1 1 IORR1000-30-CC-AME FPL8716325R0116 61
800 750 720 600 1 220...230 1 1 IORR1400-10-CC-AME FPL6116125R0116 42
1000 2 1 1 IORR1400-20-CC-AME FPL6116225R0116 52
1500 1500 3 1 1 IORR1400-30-CC-AME FPL6116325R0116 62
600 1 220...230 1 1 IORR1700-10-CC-AME FPL6216125R0116 43
- 1000 2 1 1 IORR1700-20-CC-AME FPL6216225R0116 57
1500 3 1 1 IORR1700-30-CC-AME FPL6216325R0116 71
1000 750 720 600 1 220...230 1 1 IORR2100-10-CC-AME FPL6316125R0116 46
1000 2 1 1 IORR2100-20-CC-AME FPL6316225R0116 62
1500 1500 3 1 1 IORR2100-30-CC-AME FPL6316325R0116 78
On 1 220...230 1 1 IORR2500-10-CC-AME FPL6716125R0116 On
- request 2 1 1 IORR2500-20-CC-AME FPL6716225R0116 request
3 1 1 IORR2500-30-CC-AME FPL6716325R0116
1250 750 720 On 1 220...230 1 1 IORR3200-10-CC-AME FPL6516125R0116 On
request 2 1 1 IORR3200-20-CC-AME FPL6516225R0116 request
1500 3 1 1 IORR3200-30-CC-AME FPL6516325R0116
On 1 220...230 1 1 IORR3800-10-CC-AME FPL6616125R0116 On
- request 2 1 1 IORR3800-20-CC-AME FPL6616225R0116 request
On 1 220...230 1 1 IORR4500-10-CC-AME FPL6816125R0116 On
1600 750 720 request 2 1 1 IORR4500-20-CC-AME FPL6816225R0116 request
On 1 220...230 1 1 IORR5100-10-CC-AME FPL6916125R0116 On
1500 request request

-

2000 750 720

1500

-

2300 750 On
1500 request

-

3200 750 On
1500 request

-

3800 750 On
1500 request

4500 750 On
1500 request

5000 750 On 1SBC104071S0201 - Rev. A
request

(1) Other control voltages see voltage code table.
(2) Other auxiliary contact arrangements, see auxiliary contact code table.
(3) Power circuit above 1500 V DC, please consult us.
