Questionnaire
Voltage detector selection
Company: Name:
Address:
Tel: Fax: Email:
Application Sensor environmental conditions
1. Project name ................................................................................... 1. Minimum operating temperature ................................................ (°C)
2. Application: 2. Maximum operating temperature ............................................... (°C)
Short or long distance train: 3. Average nominal operating temperature ..................................... (°C)
– Power converter ..................................................................... ■ 4. Pollution degree .............................................................................. 5
– Auxiliary converter ................................................................... ■ 5. Over voltage category (from OV1 to OV3) .........................................
Metro or tramway: 6. Maximum ambient light level ...................................................... (lux)
– Power converter ..................................................................... ■ 7. Main reference standards ................................................................
– Auxiliary converter ................................................................... ■
Fixed equipment (e.g. substation) ................................................ ■
3. Quantity per year: ...........................................................................
4. Total quantity for the project.............................................................
Electrical characteristics
1. Nominal voltage (U PN) ............................................................ (V DC)
2. Maximum voltage long duration: 5 min (U MAX2) ........................ (V DC)
3. Maximum voltage overload: 20 ms (U MAX3) .............................. (V DC)
4. Minimum voltage to be detected ................................................. (V)
Other requirements (description)
1SBC140074S0201 1SBC140074S0201
This document is used for selecting sensors according to the application and the clients requirements.
