Questionnaire
Industry current sensor selection

Company: Name:

Address:

Tel: Fax: Email:

Application Electrical characteristics
1. Application : 1. Nominal current (I PN) ......................................................... (A r.m.s.)
– Variable speed drive ................................................................ ■ 2. Current type (if possible, show current profile on graph):
– UPS ....................................................................................... ■ – Direct ..................................................................................... ■
– Wind generator ....................................................................... ■ – Alternating .............................................................................. ■
5
– Active harmonic filter ............................................................... ■ 3. Bandwidth to be measured ...................................................... (Hz)
– Welding machines ................................................................... ■ 4. Current measuring range:
– Solar ...................................................................................... ■ – Minimum current .................................................................... (A)
– Other (description) ...................................................................... – Maximum current ................................................................... (A)
2. Quantity per year: ........................................................................... – Duration (of max. current) .................................................... (sec)
– Repetition (of max. current) ........................................................ .
– Measuring voltage (on R M) at max current .............................. (V)
Mechanical characteristics
5. Overload current (not measurable):
1. Sensor fixing: – Not measurable overload current ........................................... (A)
– By soldering to the PCB .......................................................... ■ – Duration.............................................................................. (sec)
– By the enclosure ..................................................................... ■ – Repetition ...................................................................................
– By the primary conductor ........................................................ ■ 6. Sensor supply voltage:
2. Primary conductor: – Bipolar supply voltage .......................................................... (±V)
– Cable diameter ................................................................... (mm) – Unipolar supply voltage .......................................... (0 +V or 0 -V)
– Cable connection size ......................................................... (mm) 7. Output current
– Bar size .............................................................................. (mm) – Secondary current at nominal current I PN ............................. (mA)
3. Secondary connection: 8. Current output (NCS range only)
– By connector .......................................................................... ■ – Secondary current at maximum current I PMAX ....................... (mA)
– By cable without connector ..................................................... ■ 9. Voltage output
– Other ...................................................................................... ■ – Secondary voltage at nominal current I PN ............................... (V)
10. Voltage output (NCS range only)
– Secondary voltage at maximum current I PMAX ......................... (V)
Sensor environmental conditions
1. Minimum operating temperature ................................................ (°C)
2. Maximum operating temperature ............................................... (°C)
3. Presence of strong electromagnetic fields .................................... ■
4. Max. continuous primary conductor voltage ................................ (V)
5. Main reference standards ................................................................

Other requirements (description)

1SBC140074S0201

This document is used for selecting sensors according to the application and the clients requirements.
