36 ABB PILOT DEVICES – THE COMPLETE OFFERING

—

Modular range
Reset pushbuttons

—
02
Description
1SFC151235V0001 Reset pushbuttons are momentary and include only black plastic bezel.

Type
Color
Text
Pkg
Order code
(1 pce)
qty Weight
KPR1-100G
kg
1SFC151234V0001 Flush reset pushbutton KPR1-100R 1SFA616160R1001 10 0.020
l Red
No text
KPR1-101L l Green No text KPR1-100G 1SFA616160R1002 10 0.020
1SFA616160R1022
I
10
KPR1-102G
0.020
1SFC151229V0001 l Yellow II KPR1-103G 1SFA616160R1032 10 0.020
10
1SFA616160R1003
0.020
No text
KPR1-100Y
KPR1-100L
No text
10
0.020
l Blue
1SFA616160R1004
R KPR1-101L 1SFA616160R1014 10 0.020
KPR1-104B White No text KPR1-100W 1SFA616160R1005 10 0.020
R KPR1-101W 1SFA616160R1015 10 0.020
▲ I KPR1-102W 1SFA616160R1025 10 0.020
II KPR1-103W 1SFA616160R1035 10 0.020
185 mm
l Black No text KPR1-100B 1SFA616160R1006 10 0.020
RESET KPR1-104B 1SFA616160R1046 10 0.020
▲
Extended reset pushbutton
l Red No text KPR2-100R 1SFA616161R1001 10 0.021
O KPR2-105R 1SFA616161R1051 10 0.021
l Blue No text KPR2-100L 1SFA616161R1005 10 0.021
l Black No text KPR2-100B 1SFA616161R1006 10 0.021
O KPR2-105B 1SFA616161R1056 10 0.021
—
1SFC151381V0001 Accessories Type Order code Pkg Weight
kg
KA1-8047 qty (1 pce)
Shaft KA1-8046 1SFA616920R8046 10 0.007
Flexible joint KA1-8047 1SFA616920R8047 10 0.005

1.5 0.06" - 6 0.24" 1.5 0.06" - 6 0.24"

20 0.79" Ø 29 1.14" Ø 29 1.14"

9 0.35" (1) 26 1.02" 13 0.51" 26 1.02" 13 0.51"
L = 40-200 (2) 17.5 0.69" 17.5 0.69"
KPR1, KPR2 1SFC151025S0201
Dimensions (mm, inches)
