38 ABB PILOT DEVICES – THE COMPLETE OFFERING
—
Modular range
Joysticks
—
02
Description
IP protection degree : IP66, IP67 and IP69K. 4-position holder included.
1SFC151344V0001 Position Bezel Type Order code Pkg Weight
(1 pce)
qty
kg
Without latching function
MJS1-60B
Black plastic MJS1-40B 1SFA611701R4006 1 0.043
Chrome metal MJS1-60B 1SFA611701R6006 1 0.052
Black plastic MJS2-40B 1SFA611702R4006 1 0.043
Chrome metal MJS2-60B 1SFA611702R6006 1 0.052
Black plastic MJS3-40B 1SFA611703R4006 1 0.043
Chrome metal MJS3-60B 1SFA611703R6006 1 0.052
Black plastic MJS4-40B 1SFA611704R4006 1 0.043
Chrome metal MJS4-60B 1SFA611704R6006 1 0.052
Black plastic MJS5-40B 1SFA611705R4006 1 0.043
Chrome metal MJS5-60B 1SFA611705R6006 1 0.052
Black plastic MJS6-40B 1SFA611706R4006 1 0.043
Chrome metal MJS6-60B 1SFA611706R6006 1 0.052
With latching function
Black plastic MJS7-40B 1SFA611707R4006 1 0.043
Chrome metal MJS7-60B 1SFA611707R6006 1 0.052
Black plastic MJS9-40B 1SFA611709R4006 1 0.043
Chrome metal MJS9-60B 1SFA611709R6006 1 0.052
Black plastic MJS8-40B 1SFA611708R4006 1 0.043
Chrome metal MJS8-60B 1SFA611708R6006 1 0.052
Chrome metal MJS10-60B 1SFA611710R6006 1 0.052
Black plastic MJS12-40B 1SFA611712R4006 1 0.043
Chrome metal MJS12-60B 1SFA611712R6006 1 0.052
Black plastic MJS11-40B 1SFA611711R4006 1 0.043
Chrome metal MJS11-60B 1SFA611711R6006 1 0.052
—
Accessories
1SFC151481F0001 Type Order code Pkg Weight
(1 pce)
qty
MA1-8138 kg
Legend plates, 66 x 59 aluminum laminate with adhesive back
2-position - Up - Down MA6-1240 1SFA611930R1240 10 0.004
1SFC151480F0001 4-position Up - down - right - left MA6-1242 1SFA611930R1242 10 0.004
MA6-1241
1SFA611930R1241
10
2-position - Left - Right
0.004
MA1-8138
1SFA611920R8138
2-position
MA1-8137 Legend plates holder (inserts not included, suitable for insert size 27x15) 10 0.002
4-position MA1-8137 1SFA611920R8137 10 0.003
1.5 0.06" - 6 0.24" 1.5 0.06" - 6 0.24"
27 1.06"
43 1.69" Ø 29 1.14" Ø 29 1.14"
40 1.57" 48.5 1.91" 71 2.80" 48.5 1.91" 71 2.80"
without latching function with latching function 1SFC151028S0201
MJS
Dimensions (mm, inches)
