Page 145 - 1SNC160023C0204_Marking_systems_catalog_EN

RC1010 terminal block markers
Pre-printed markers for SNA and Solution series

10 mm 0.394 in spacing - vertical mounting

1SNC160190F0014 Description

–– Save printing time with our large pre-printed cards offer with pre-printed numbers, letters or symbols,
–– To be used to mark screw clamp, spring loaded screw clamp, spring clamp and distribution terminal

blocks from the SNA and Solution series.

Main technical data

Vertical terminal block Material Flammability
assembly

Polyamide V2

Ordering details Color Type Order code Pkg Weight
card (1 card) g
Description RC1010 1SNA238050R1700
RC1010 1SNA238051R0400 51 8.00
Card with 80 markers, ascending order repeated 10 times RC1010 1SNA238052R0500
RC1010 1SNA238053R0600 1 8.00
0->7 (x10) White RC1010 1SNA238054R0700 1 8.00
1->8 (x10) White RC1010 1SNA238055R0000 1 8.00
9->16 (x10) White RC1010 1SNA238056R0100 1 8.00
17->24 (x10) White RC1010 1SNA238057R0200 1 8.00
25->32 (x10) White RC1010 1SNA238058R1300 1 8.00
33->40 (x10) White RC1010 1SNA238059R1400 1 8.00
41->48 (x10) White RC1010 1SNA238060R1100 1 8.00
49->56 (x10) White RC1010 1SNA238061R0600 1 8.00
57->64 (x10) White RC1010 1SNA238062R0700 1 8.00
65->72 (x10) White RC1010 1SNA238063R0000 1 8.00
73->80 (x10) White RC1010 1SNA238064R0100 1 8.00
81->88 (x10) White RC1010 1SNA238065R0200 1 8.00
89->96 (x10) White RC1010 1SNA238066R0300 1 8.00
97->104 (x10) White RC1010 1SNA238067R0400 1 8.00
RC1010 1SNA238068R1500 1 8.00
105->112 (x10) White RC1010 1SNA238069R1600 1 8.00
113->120 (x10) White RC1010 1SNA238070R1300 1 8.00
121->128 (x10) White RC1010 1SNA238071R0000 1 8.00
129->136 (x10) White RC1010 1SNA238072R0100 1 8.00
137->144 (x10) White RC1010 1SNA238073R0200 1 8.00
145->152 (x10) White RC1010 1SNA238074R0300 1 8.00
153->160 (x10) White RC1010 1SNA238075R0400 1 8.00
161->168 (x10) White 1 8.00
169->176 (x10) White RC1010 1SNA238080R0600 1 8.00
177->184 (x10) White RC1010 1SNA238081R2300
185->192 (x10) White RC1010 1SNA238082R2400 1 8.00
193->200 (x10) White RC1010 1SNA238083R2500 1 8.00
RC1010 1SNA238084R2600 1 8.00
Card with 80 markers, ascending order RC1010 1SNA238085R2700 1 8.00
RC1010 1SNA238086R2000 1 8.00
1->80 White RC1010 1SNA238087R2100 1 8.00
81->160 White RC1010 1SNA238088R0200 1 8.00
161->240 White 1 8.00
241->320 White 1 8.00
321->400 White
401->480 White
481->560 White
561->640 White
641->720 White

1SNC160147S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
ABB Solution series - Markers and marking systems | 143
