P. 148
RC55 terminal block markers
Pre-printed markers for SNA and Solution series
5 mm 0.197 in spacing - vertical mounting
1SNC160190F0014 Description
–– Save printing time with our large pre-printed card offer with pre-printed numbers, letters or symbols,
–– To be used to mark screw clamp and spring clamp terminal blocks, and all Miniblocks, from the SNA and
Solution series.
Main technical data
Vertical terminal block Material Flammability
assembly Polyamide V2
Ordering details Color Type Order code Pkg Weight
card (1 card) g
Description RC55 1SNA230040R1100
RC55 1SNA230041R0600 1 2.70
Card with 100 markers, ascending order repeated 10 times RC55 1SNA230042R0700 1 2.70
RC55 1SNA230043R0000 1 2.70
0->9 (x10) White RC55 1SNA230044R0100 1 2.70
1->10 (x10) White RC55 1SNA230045R0200 1 2.70
5 11->20 (x10) White RC55 1SNA230046R0300 1 2.70
21->30 (x10) White RC55 1SNA230047R0400 1 2.70
31->40 (x10) White RC55 1SNA230048R1500 1 2.70
41->50 (x10) White RC55 1SNA230049R1600 1 2.70
51->60 (x10) White RC55 1SNA230050R1300 1 2.70
61->70 (x10) White RC55 1SNA230051R0000 1 2.70
71->80 (x10) White RC55 1SNA230052R0100 1 2.70
81->90 (x10) White RC55 1SNA230053R0200 1 2.70
91->100 (x10) White RC55 1SNA230054R0300 1 2.70
101->110 (x10) White RC55 1SNA230055R0400 1 2.70
111->120 (x10) White RC55 1SNA230056R0500 1 2.70
121->130 (x10) White RC55 1SNA230057R0600 1 2.70
131->140 (x10) White RC55 1SNA230058R1700 1 2.70
141->150 (x10) White RC55 1SNA230059R1000 1 2.70
151->160 (x10) White RC55 1SNA230072R0500 1 2.70
161->170 (x10) White RC55 1SNA230060R1500 1 2.70
171->180 (x10) White RC55 1SNA230061R0200
181->190 (x10) White RC55 1SNA230062R0300 1 2.70
191->200 (x10) White RC55 1SNA230063R0400 1 2.70
RC55 1SNA230064R0500 1 2.70
Card with 100 markers, ascending order White RC55 1SNA230065R0600 1 2.70 1SNC160149S0201
1->100 White RC55 1SNA230066R0700 1 2.70
101->200 White RC55 1SNA230067R0000 1 2.70
201->300 White RC55 1SNA230068R1100 1 2.70
301->400 White RC55 1SNA230069R1200 1 2.70
401->500 White RC55 1SNA230180R0300 1 2.70
501->600 White RC55 1SNA230181R2000 1 2.70
601->700 White RC55 1SNA230182R2100
701->800 White RC55 1SNA230183R2200 1 2.70
801->900 White RC55 1SNA230184R2300 1 2.70
901->1000 White RC55 1SNA230185R2400 1 2.70
White RC55 1SNA230186R2500 1 2.70
Card with 100 markers, repeated identical letters White RC55 1SNA230187R2600 1 2.70
A (x100) White RC55 1SNA230188R0700 1 2.70
B (x100) White RC55 1SNA230189R0000 1 2.70
C (x100) White RC55 1SNA230190R0500 1 2.70
D (x100) White RC55 1SNA230191R2200 1 2.70
E (x100) White RC55 1SNA230192R2300 1 2.70
F (x100) White RC55 1SNA230193R2400 1 2.70
G (x100) White RC55 1SNA230194R2500 1 2.70
H (x100) White RC55 1SNA230195R2600 1 2.70
I (x100) White RC55 1SNA230196R2700 1 2.70
J (x100) White RC55 1SNA230197R2000 1 2.70
K (x100) White RC55 1SNA230198R0100 1 2.70
L (x100) White RC55 1SNA230199R0200 1 2.70
M (x100) White RC55 1SNA230200R2700 1 2.70
N (x100) White RC55 1SNA230201R1400 1 2.70
O (x100) White RC55 1SNA230202R1500 1 2.70
P (x100) White RC55 1SNA230203R1600 1 2.70
Q (x100) White RC55 1SNA230204R1700 1 2.70
R (x100) White RC55 1SNA230205R1000 1 2.70
S (x100) White 1 2.70
T (x100) White 1 2.70
U (x100) White 1 2.70
V (x100) White
W (x100) White
X (x100)
Y (x100)
Z (x100)
All the technical data for UL/CSA standard and dimensions in inches are in italic.
