RCAL85 terminal block markers
Pre-printed markers for SNA and Solution series

8 mm 0.315 in spacing - horizontal mounting

Description

–– Save printing time with our large pre-printed card offer with pre-printed numbers, letters or symbols,
–– To be used to mark spring clamp terminal blocks and ADO System® Miniblocks from the SNA and Solution

series.

1SNC160191F0014 Main technical data

Material Flammability

Polyamide V2

Horizontal terminal block Ordering details
assembly
Description
Color Type Order code Pkg Weight
card (1 card) g
Card with 100 markers, ascending order repeated 10 times RCAL85 1SNA237001R2200
RCAL85 1SNA237002R2300 51 2.90
0->9 (x10) White RCAL85 1SNA237003R2400
RCAL85 1SNA237004R2500 1 2.90
1->10 (x10) White RCAL85 1SNA237005R2600 1 2.90
RCAL85 1SNA237006R2700 1 2.90
11->20 (x10) White RCAL85 1SNA237007R2000 1 2.90
RCAL85 1SNA237008R0100 1 2.90
21->30 (x10) White RCAL85 1SNA237009R0200 1 2.90
RCAL85 1SNA237010R2600 1 2.90
31->40 (x10) White RCAL85 1SNA237011R1300 1 2.90
RCAL85 1SNA237012R1400 1 2.90
41->50 (x10) White RCAL85 1SNA237013R1500 1 2.90
RCAL85 1SNA237014R1600 1 2.90
51->60 (x10) White RCAL85 1SNA237015R1700 1 2.90
RCAL85 1SNA237016R1000 1 2.90
61->70 (x10) White RCAL85 1SNA237017R1100 1 2.90
RCAL85 1SNA237018R2200 1 2.90
71->80 (x10) White RCAL85 1SNA237019R2300 1 2.90
RCAL85 1SNA237020R2000 1 2.90
81->90 (x10) White RCAL85 1SNA237021R1500 1 2.90
1 2.90
91->100 (x10) White 1 2.90

101->110 (x10) White

111->120 (x10) White

121->130 (x10) White

131->140 (x10) White

141->150 (x10) White

151->160 (x10) White

161->170 (x10) White

171->180 (x10) White

181->190 (x10) White

191->200 (x10) White

Card with 100 markers, ascending order White RCAL85 1SNA237030R2200 1 2.90
White RCAL85 1SNA237031R1700 1 2.90
1->100 White RCAL85 1SNA237032R1000 1 2.90
101->200 White RCAL85 1SNA237033R1100 1 2.90
201->300 White RCAL85 1SNA237034R1200 1 2.90
301->400 White RCAL85 1SNA237035R1300 1 2.90
401->500 White RCAL85 1SNA237036R1400 1 2.90
501->600 White RCAL85 1SNA237074R2200 1 2.90
601->700 White RCAL85 1SNA237075R2300 1 2.90
701->800 White RCAL85 1SNA237076R2400 1 2.90
801->900
901->1000

Card with 100 markers, 5 different symbols repeated 20 times

L1-L2-L3-N-PE (x20) White RCAL85 1SNA237131R1000 1 2.90

Card with 100 markers, 9 different symbols repeated 10 times

U1-U2-U3-V1-V2-V3-W1-W2-W3 (x10) + U1 (x10) White RCAL85 1SNA237132R1100 1 2.90

1SNC160152S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
