EPU terminal block markers
Pre-printed cover marker for SNA series

5 mm 0.197 in to 12 mm 0.472 in spacing - top marking

1SNC700193F0000 Description

–– Protective label used to indicate live circuits,
–– Prohibits access to connection screws,
–– To be snapped directly onto the terminal block,
–– To be used to cover one single screw clamp terminal block from the SNA and Solution series.

Main technical data

EPU5 Material Flammability

Polyamide V2

Ordering details

Description Color Type Order code Pkg Weight
card (1 card) g

5 5 mm 0.197 in spacing

EPU5 Yellow EPU5 1SNA107033R1000 1 2.00

For MA2,5/5 SNA terminal blocks
Yellow label with black arrow

6 mm 0.237 in to 10 mm 0.394 in spacing

EPU6

For M4/6, M6/8, M10/10 and M16/12 SNA terminal blocks (use two labels for M16/12)

Yellow label with black arrow Yellow EPU6 1SNA107038R2500 1 2.00

1SNC160157S0201 - Rev. A

All the technical data for UL/CSA standard and dimensions in inches are in italic.
