MG3 markers selection guide
for other manufacturers' terminal blocks

Terminal block Depending on type, markers are presented as
joined strips at a set or as separate markers
MG-CPM terminal block markers are available for convenient individual insertion on mixed
in versions to suit the particular terminal block spacing terminal block assemblies.
formats of the most widely used products, see
selection guide to side.

Markers Individual markers

Strip markers Marker spacing
Marker width
6 Marker spacing

Marker width

Strip mounting (Marker spacing = Terminal block spacing)

P - Single clips to spacing

Marker width = Terminal block width

M - Modular strip

Marker width < Terminal block width

CP - Single clips compatible to spacing

Marker width < Terminal block width

Individual mounting (Marker spacing ≠ Terminal block spacing)

S - Single clips

Marker width = Terminal block width

C - Single clips compatible

Marker width < Terminal block width 1SNC160219S0201
