P. 76
MG-VRT-A panel plates
Self-adhesive blank panel plates
Description
–– To be used in identifying panels and cabinets with technical data or logos,
–– Made of rigid PVC.
1SNC160143F0014 Main technical data Flammability Temperature range
V0 -30°C to +80°C -22°F to +176°F
Material
Rigid PVC
3 Ordering details
MG-VRT-A 88903 Dimensions Nb. of Color Type Order code SW Pkg Weight
mm in markers code marker (1 marker) g
per card 50 9.90
Self-adhesive panel plate for direct application on suitable surfaces 1 148.50
52 x 107 2.047 x 4.213 2 White MG-VRT-A 88903 1SNB088903R0052 204
Marking system accessories MG2-PLT 991002 1SNB991002R0000
MG2-PLT
Support plate
Included in the MG3 Kit
MG-VRT-R panel plates
Blank panel plates
Description
–– To be used in identifying panels and cabinets with technical data or logos,
–– To be fixed with rivets,
–– Made of rigid PVC.
Main technical data Flammability Temperature range
V0 -30°C to +80°C -22°F to +176°F
Material
Rigid PVC
1SNC160144F0014
MG-VRT-R 48903 40 1.57"Ordering detailsNb. of ColorTypeOrder codeSW Pkg Weight
1SNC160185S0201 - Rev. AmarkersMG-VRT-R 48903codemarker (1 marker) g
Dimensions per card 100 6.40
White 1SNB048903R0052 204
mm in 2 1 148.50
Rivet fixing panel plate
52 x 107 2.047 x 4.213
Marking system accessories MG2-PLT 991002 1SNB991002R0000
MG2-PLT
Support plate
Included in the MG3 Kit
Mounting instruction
90 3.54"
All the technical data for UL/CSA standard and dimensions in inches are in italic.
