MG-TAPW component and equipment markers
Precut blank labels

Description

–– 9 mm 0.354 in width versatile label used to identify a wide range of devices,
–– Use with label rail holders RTA-TAPW 990653N,
–– Made of rigid PVC.

3 1SNC160137F0014 Main technical data Flammability Temperature range
V0 -30°C to +80°C -22°F to +176°F
MG-TAPW Material
Rigid PVC

Ordering details Nb. of Color Type Order code SW Pkg Weight
markers code
Dimensions per card MG-TAPW 49042N marker (1 marker) g
MG-TAPW 49093N 2200 0.10
mm in 88 Yellow MG-TAPW 49043N 1SNB049042R0912 360 1925 0.20
77 White MG-TAPW 49090N 1SNB049093R0915 361 1925 0.20
9 x 12 0.354 x 0.472 Yellow MG-TAPW 49040N 1SNB049043R0915 361 2750 0.20
9 x 15 0.354 x 0.591 White MG-TAPW 49096 1SNB049090R0920 362 2750 0.60
Yellow MG-TAPW 49046 1SNB049040R0920 362 1500 0.30
9 x 20 0.354 x 0.787 55 White MG-TAPW 49091N 1SNB049096R0929 363 1500 0.30
Yellow 1SNB049046R0929 363 1650 0.40
9 x 29 0.354 x 1.142 30 White 1SNB049091R0935 364
1 148.50
9 x 35 0.354 x 1.378 33

Marking system accessories MG2-PLT 991002 1SNB991002R0000

MG2-PLT
Support plate
Included in the MG3 Kit

Compatible holders

PEAD
(only for MG-TAPW 49096 and 49046)

RTA-TAPW self-adhesive rail marker holders
For MG-TAPW labels

1SNC700116F0000 Description

–– Provide an alternative to direct marking on components,
–– Compatible with 9 mm 0.354 in MG-TAPW labels,
–– Non-deformable up to 90°C, resistant to acid, alcohol, solvents.

RTA-TAPW

Main technical data Flammability Temperature range
V0 +10°C to + 40°C +50°F to +104°F
Material
Rigid dielectric high-impact PVC

Ordering details Nb. of Color Type Order code Pkg Weight
markers 1SNB990653R0000 pce (1 pce) g
Dimensions per card 1SNC160177S0201
25 47.50
mm in

RTA-TAPW

Self-adhesive rail Grey RTA-TAPW 990653N
9 x 430 0.354 x 16.929

All the technical data for UL/CSA standard and dimensions in inches are in italic.

70 | ABB Solution series - Markers and marking systems
