Screw clamp technology - SNK series, terminal blocks

Features and benefits

Easy to install
Smart design facilitating assembly process.
Mounting, wiring, testing… made easy

Avoid mounting and wiring errors: asymmetrical design allows
immediate visual check in case of reversed terminal blocks.
3

Asymmetrical design avoids mounting error.

Minimize retightening campaigns
High torque resistance : the clamp is punched to increase the
number of threads in contact by 30 % 1 .
The ABB exclusive anti-release system creates a controlled
locking-screw effect reinforced by the 2 overlapping tabs that
maintain the clamp parts 2 .

1 2

High torque resistance. Anti-release system.

Faster accessories mounting
Save up to 70% mounting time thanks to screwless accessories:
jumpers, component plugs, test devices, end stops and snap-in
ground terminal blocks.

Screwless accessories Snap-in ground terminal
block for rapid installation

1SNK161092S0201
