Measuring and monitoring relays
Benefits and advantages

CM-N range: Multifunctional CM-S range: CM-E range: Economy
Universal and multifunctional
2

– 45 mm wide housing – Only 22.5 mm wide housing – Only 22.5 mm wide housing
– Output contacts: 2 c/o (SPDT) contacts – Output contacts: 1 or 2 c/o (SPDT) con- – Output contacts: 1 c/o
– Continuous voltage range (24-240 V AC/DC)
tacts contact or 1 n/o contact
or single-supply – One supply voltage range or supplied by – One supply voltage range
– Setting and operation via front-face operat- – One monitoring function
measuring circuit – Cost-efficient solution for
ing controls – Setting and operation via front-face
– Adjustment of threshold values and switch- OEM applications
operating controls – Preset monitoring ranges
ing hysteresis via direct reading scale – Adjustment of threshold values and
– Adjustable time delays
– Integrated and snap-fitted front-face marker switching hysteresis via direct reading
scale
label – Integrated and snap-fitted front-face
– Sealable transparent cover (accessory) marker
– Snap-on housing: The relays can be
placed on a DIN rail tool-free - just snap
it on or remove it tool-free
– Sealable transparent cover (accessory)

ABB‘s measuring and monitoring relays in a new housing
Benefits at a glance

Easy Connect Technology Extended features
New options: Flammability:
Additionally to the existing well established screw connections The plastic housing material used meets the requirements for
a new innovative connection technology can be offered: Easy the highest flammability class. (UL94 V-0 rated)
Connect Technology with push-in terminals.
Look and feel:
Tool-free wiring: The new housing fits perfectly with ABB’s control products
The push-in terminals can be wired with rigid or fine stranded offer.
wires with wire end ferrules totally tool-free. The connection
direction is exactly the same as the screw version.

Higher utility class:
The Easy Connect Technology provides excellent vibration
resistance with gas tight push-in terminals – the right solution
for harsh environment.

2/3 ABB | Catalog Electronic Products and Relays 2015 | 2CDC 110 004 C0210
