Measuring and monitoring relays
Benefits and advantages
Higher utility class 1 Double-chamber cage connection terminals 4 2
The Easy Connect Technology provides excellent vibration Double-chamber cage connection terminals provide connec-
resistance with gas tight push-in terminals – the right solu- tion of wires up to 2 x 0.5-2.5 mm² (2 x 20-14 AWG) rigid or
tion for harsh environment. Selected products of the elec- fine-strand, with or without wire end ferrules. Potential dis-
tronic timers and measuring and monitoring relays comply tribution does not require additional terminals. The extended
to the latest rail standards NF F 16-101/102, EN 45545, type designators for products with double-chamber cage con-
EN 50155 and more standards which are relevant for rail- nection terminals are indicated by a S following the extended
way applications. Find more inforamtion in the rail brochure type designator e.g. CM-xxS.xxS.
2CDC110084B0201.
LED‘s for status indication 5
Safety 2 All actual operational states are displayed by front-face LEDs,
The „real distance“ is hidden. thus simplifying commissioning and troubleshooting.
The clearance and the creepage distances of our products
exceed international standards and substantially increase the Integrated marker label 6
safety of our products. Integrated marker labels allow the product to be marked
quickly and simply. No additional marker labels are required.
Easy Connect Technology 3
Tool-free wiring and excellent vibration resistance. Push-in Sealable transparent cover 7
terminals provide connection of wires up to 2 x 0.5 - 1.5 mm² Protection against unauthorized changes of time and thresh-
(2 x 20 -16 AWG), rigid or fine-strand with or without wire old values. Available as an accessory.
end ferrules. The extended type designators for products with
push-in terminals are indicated by a P following the extended Snap-On housing 8
type designator e.g. CM-xxS.xxP. Tool-free DIN rail installation and deinstallation of the monitor-
ing relay.
13 5 71SVC 110 000 F0506 2CDC 253 026 F0011 2CDC 252 006 F0012 2CDC 255 006 S0011
2 4 6 88
2CDC 253 011 F0003 2CDC 253 025 F0011 2CDC 253 007 F0012 2CDC 253 013 F0013
