Current and voltage monitoring relays, single-phase
Ordering details - Current monitoring relays

2 Description

CM-SRS.22S The CM range current monitoring relays protect single-phase mains (DC or AC) from over- and
undercurrent from 3 mA to 15 A. Two different terminal versions are available. You can choose
between the proven screw connection technology (double-chamber cage connecting termi-
nals) and the completely tool-free Easy Connect Technology (push-in terminals).

Ordering details

Rated control Function Tripping Measuring Type Order code Price Weight
range 1SVR730840R0200 1 pce (1 pce)
supply voltage delay TV kg (lb)

24-240 V AC/DC 0.145 (0.320)

110-130 V AC CM-SRS.11S 1SVR730841R0200 0.161 (0.355)

220-240 V AC b 3-30 mA, 1SVR730841R1200 0.161 (0.355)
10-100 mA, 1SVR740840R0200 0.137 (0.302)
a without 0.1-1 A
24-240 V AC/DC
2CDC 251 054 V0011
110-130 V AC CM-SRS.11P 1SVR740841R0200 0.153 (0.337)

220-240 V AC 1SVR740841R1200 0.153 (0.337)

24-240 V AC/DC 1SVR730840R0300 0.137 (0.302)
CM-SRS.12S 1SVR730841R0300 0.168 (0.370)
110-130 V AC b without 0.3-1.5 A, 0.168 (0.370)
a 1-5 A, 1SVR730841R1300
3-15 A

220-240 V AC

24-240 V AC/DC 1SVR730840R0400 0.152 (0.335)

110-130 V AC CM-SRS.21S 1SVR730841R0400 0.179 (0.395)

220-240 V AC b adjustable 3-30 mA, 1SVR730841R1400 0.179 (0.395)
0 or 0.1-30 s 10-100 mA, 1SVR740840R0400 0.141 (0.311)
a 0.1-1 A
24-240 V AC/DC

110-130 V AC CM-SRS.21P 1SVR740841R0400 0.168 (0.370)

220-240 V AC 1SVR740841R1400 0.168 (0.370)

24-240 V AC/DC 1SVR730840R0500 0.144 (0.399)
CM-SRS.22S 1SVR730841R0500 0.181 (0.399)
110-130 V AC b adjustable 0.3-1.5 A, 0.181 (0.399)
a 0 or 0.1-30 s 1-5 A, 1SVR730841R1500
3-15 A

220-240 V AC

2CDC 251 056 V0011 24-240 V AC/DC b adjustable 3-30 mA, CM-SRS.M1S 1SVR730840R0600 0.153 (0.337)
24-240 V AC/DC e 0 or 0.1-30 s 10-100 mA, CM-SRS.M1P 1SVR740840R0600 0.142 (0.313)
a 0.1-1 A 1SVR730840R0700 0.155 (0.342)
f 1SVR730760R0400 0.150 (0.331)
adjustable 0.3-1.5 A, CM-SRS.M2S 1SVR740760R0400 0.139 (0.306)
0 or 0.1-30 s 1-5 A,
3-15 A 0.158 (0.348)

CM-SFS.22P b adjustable 3-30 mA, CM-SFS.21S
e 0 or 0.1-30 s 10-100 mA, CM-SFS.21P
24-240 V AC/DC a 0.1-1 A
24-240 V AC/DC f
b Overcurrent monitoring j adjustable 0.3-1.5 A, CM-SFS.22S 1SVR730760R0500
a Undercurrent monitoring i 0 or 0.1-30 s 1-5 A,
e Without latching 3-15 A
f With latching
j 1x2 c/o (SPDT) contacts S: screw connection
i 2x1 c/o (SPDT) contact P: push-in / easy connect
