CP600 series and CP400 series

HMI panels and control panels

HMI panels
Resolution Display size Type Order code Price Weight
(1 pce)
pixels kg
480 x 272 4.3" CP620 1SAP520100R0001 0.950
320 x 240 5.7" CP630 1SAP530100R0001 1.150
800 x 480 7.0" CP635 1SAP535100R0001 1.100
800 x 600 10.4" CP650 1SAP550100R0001 2.100
800 x 600 12.1" CP660 1SAP560100R0001 2.900
CP650 1024 x 768 15.0" CP675 1SAP575100R0001 3.800
480 x 272 4.3" CP620-WEB 1SAP520200R0001 0.950
320 x 240 5.7" CP630-WEB 1SAP530200R0001 1.150
800 x 480 7.0" CP635-WEB 1SAP535200R0001 1.100
800 x 600 10.4" CP650-WEB 1SAP550200R0001 2.100
800 x 600 12.1" CP660-WEB 1SAP560200R0001 2.900
1024 x 768 15.0" CP675-WEB 1SAP575200R0001 3.800
Communication cables (connection control panel <-> PLC)
Description Type Order code Price Weight
(1 pce)
kg
Communication cable RS232: CP600-AC500 TK681 1SAP500981R0001 0.130
Communication cable RS485: CP600-AC500-eCo TK682 1SAP500982R0001 0.130
7
Programming software
Description Type Order code Price Weight
(1 pce)
kg
Panel Builder 600 (1) PB610 1SAP500900R0001 0.150
(included in Automation Builder software suite)
(1) Delivery includes the programming software and corresponding documentation for software and control panels on USB-ROM.

Control panels
Resolution Display Type Order code Price Weight
(1 pce)
pixels kg
240 x 240 3.5", 16 grey levels CP415M 1SBP260191R1001 0.230
320 x 240 5.7", 16 blue levels CP430B 1SBP260183R1001 0.810

CP415 Programming cables
Plug on CP400 Description Type Order code Price Weight
side (1 pce)
kg
Sub-D 9 Connection to COM1. TK401 1SBN260216R1001 0.180
Length: 4 m
Sub-D 25 Connection to COM2. TK402 1SBN260217R1001 0.230
Length: 4 m

Communication cables (connection control panel <-> PLC)
Plug on PLC PLC Type Order code Price Weight
side (1 pce)
kg
Sub-D 9 AC500 TK405 1SBN260221R1001 0.130
Sub-D 9 AC500-eCo TK406 1SBN260224R1001 0.130
Programming software
Description Type Order code Price Weight
(1 pce)
kg
Programming software for CP400 (1) CP400Soft 1SBS260284R1001 0.100
(1) Delivery includes the programming software and corresponding documentation on CD-ROM.
