Standards

Enclosures

Foundation
In the CDC range, the ground foundation is an integral
part of the design. The length of the legs are individually
adjustable and they can be angled out to avoid
protruding building foundations. Separate foundations for
ground, floor or wall mounting are available for the SDC
3 range.

In all below-ground parts, the corrosion protection has Integrated adjustable foundation
been reinforced with a polymer coating to achieve a in enclosure CDC.
heavy-duty corrosion protection. To make sure that the
polymer coat adheres to the hot-dip galvanized surface,
it has undergone zinc/manganese phosphating. This
treatment gives excellent protection against corrosion, so
that the life of the enclosures is very long
in the most commonly occurring environments for
outdoor enclosures.

KSIK enclosures are for wall mounting indoors only.

Frost heave and CDC
A sliding bar system in the enclosures type CDC reduces
the problems that may arise in connection with frost
heave. Sliding busbar counteracts Marking pole made of strong
damages from frost heave. steel and equipped with signal
External fixing points marking and reflective tape.
The sides of all enclosures except the indoor enclosure
KSIK are fitted with rivet-nuts to attach marking poles,
other enclosures, boxes, etc.

Openings for temporary outlets
Both sides of CDC and SDC enclosures have an opening
for a temporary power outlet or to make protected
connections between two enclosures. The openings are
fitted with a revolving seal with a choice of five openings,
the largest of which is Ø 60 mm.

Where more SDC enclosures are to be combined, special
sides with openings are available. Temporary openings at both
sides of the enclosures.
For further information contact your supplier or us.

On KSIK, there are two covered flange openings, size FL
33 in each side panel.

Marking
There is a space for marking at the top of the door of
enclosures CDC. On the inside of the door there is a clip
to attach a cable distribution cabinet card, etc.

Locks
The enclosures have different locks depending on their Space for marking at the top of Lock for enclosures.
field of application,see the page “Locks and tools“. the door of enclosures CDC.
