MG2-TDMO wire and cable markers
Clip-on cable blank markers

Description
– To be directly printed and clip onto the wire,
– Partially printed marker cards may be re-used to avoid wastage,
– Made of rigid polycarbonate.
Main technical data Flammability Temperature range
1SNC160118F0014 Polycarbonate V0 -40°C to +140°C -40°F to +284°F
Material

Ordering details
MG2-TDMO-01
Dimensions Nb. of Color Type Part Number SW Pkg Weight
markers code
mm in per card marker (1 marker) g
Cable Ø 2-2.9 mm 0.07-0.11 in Section 0.5-1.5 mm²
MG2-TDMO-01
4 x 12 0.157 x 0.472 40 White MG2-TDMO-01 40390 1SNB040390R0412 125 880 0.30
Yellow MG2-TDMO-01 40340 1SNB040340R0412 125 800 0.30
4 x 16 0.157 x 0.630 White MG2-TDMO-01 40391 1SNB040391R0416 128 880 0.30
Yellow MG2-TDMO-01 40341 1SNB040341R0416 128 800 0.30
3
Cable Ø 2.9-3.5 mm 0.11-0.14 in Section 1.5-2.5 mm²
MG2-TDMO-02
4 x 12 0.157 x 0.472 40 White MG2-TDMO-02 40490 1SNB040490R0412 126 640 0.40
Yellow MG2-TDMO-02 40440 1SNB040440R0412 126 640 0.40
4 x 16 0.157 x 0.630 White MG2-TDMO-02 40491 1SNB040491R0416 129 640 0.40
Yellow MG2-TDMO-02 40441 1SNB040441R0416 129 640 0.40
Cable Ø 4-4.6 mm 0.16-0.18 in Section 4-6 mm²
MG2-TDMO-03
4 x 12 0.157 x 0.472 40 White MG2-TDMO-03 40590 1SNB040590R0412 127 560 0.40
Yellow MG2-TDMO-03 40540 1SNB040540R0412 127 560 0.40
4 x 16 0.157 x 0.630 White MG2-TDMO-03 40591 1SNB040591R0416 130 560 0.40
Yellow MG2-TDMO-03 40541 1SNB040541R0416 130 560 0.40

Marking system accessories
MG2-PTM
Support plate
Purchased separately MG2-PTM 991010 1SNB991010R0000 1 116.00

Mounting instruction

1SNC160169S0201 - Rev. A
Compatible holders

UMH
