RPEV terminal block markers
Precut blank labels for SNA and Solution series

1SNC700163F0000 Description
– Precut PVC label,
– To be used with PEV pivoting marker holder.
RPEV
Main technical data
Material Flammability
PVC

Ordering details
Dimensions Nb. of Color Type Part Number Pkg Weight
markers
mm in per card card (1 card) g
RPEV
6 x 29 0.236 x 1.142 99 White RPEV 1SNA173178R0700 1 9.20

Marking system accessories
SPRC 21
Support plate for AMS600 and AMS250
Purchased separately SPRC 21 1SNA360031R0600 1 500.00

PEV pivoting terminal block marker holders 4
For RPEV markers

Description
– To be slided into 6 mm 0.236 in spacing terminal blocks,
– Can be placed side by side from 10 mm 0.394 in spacing,
– The pivoting upper part provides access to the compression screws,
– Designed to be mounted individually.

1SNC160192F0014 Main technical data Flammability
Material

PEV
Ordering details
Dimensions Nb. of Color Type Part Number Pkg Weight
markers
mm in per card pce (1 pce) g
PEV
Pivoting marker holder
6 x 29 0.236 x 1.142 Grey PEV 1SNA113180R1200 10 1.00
Dimensions given apply to the labelling area.

Mounting instruction
(1) (2) 1 - For 6 mm (0.236 in) and
8 mm (0.315 in) spacing
terminal blocks : PEV can be
6 0.24" 6 0.24" 8 0.31" used on every other block
2 - From 10 mm (0.394 in)
spacing terminal blocks : PEV
can be used side by side
29 1.14"
1SNC160119S0201
