P. 483
Dedicated applications terminal blocks
Sensors / Actuators
Screw clamp technology
2 wire sensor 3 wire sensor Thermocouple
Section
IEC UL/CSA
2.5 mm² 12 AWG D2.5/6.DP D2.5/6.DA D2.5/6.D D2.5/6.DL D2.5/6.DAL MTC6
6 mm 0.236 in 6 mm 0.236 in 6 mm 0.236 in 6 mm 0.236 in 6 mm 0.236 in 6 mm 0.236 in
Spring clamp technology
3 wire sensor 4 wire sensor
Section
IEC UL/CSA
1.5 mm² 16 AWG D2.5/5.C3.L D2.5/5.C3.L.L D2.5/5.C4.L D2.5/5.C4.L.L
5 mm 0.197 in 5 mm 0.197 in 5 mm 0.197 in 5 mm 0.197 in
9
ADO-ADO technology
3 wire sensor 4 wire sensor
1SNC160063S0201
Section
IEC UL/CSA
1 mm² 20 AWG D1/5.C3.ADO D1/5.C3.ADO.L D1/5.C4.ADO D1/5.C4.ADO.L
5 mm 0.197 in 5 mm 0.197 in 5 mm 0.197 in 5 mm 0.197 in
