Railway applications, terminal blocks
Stud technology

HD type - 1 Stud for TH35 & type 2 rails mounting

Section
4 mm² M4 HD4/9.F4
HD4/9.F4.2
HD4/10.F4.19
10 mm² M5 HD10/12.F5
HD10/12.F5.1…5.2
HD10/12.F5.3
35 mm² M6 HD35/16.F6.19
HD35/16.F6.19.1
70 mm² M8 HD70/22.F8.31
HD70/22.F8.31.1
HD70/22.F8.31.2
120 mm² HD120/30.F10.31
HD120/30.F10.31.1
185 mm² HD185/36.F12.31.1

6

HD type - 2 Studs for TH35 & type 2 rails mounting

Section
4 mm² M4 HD4/9.FF4
6 mm² M4 HD6/13.FF4
10 mm² M5 HD10/12.FF5
16 mm² M5 HD16/14.FF5.21 HD16/14.FF5.21.3 HD16/14.FF5.20.3 HD16/14.FF5.20

Clamp - Channels for jumpering or testing - Test socket - Blown-fuse indicator
