Railway applications, terminal blocks
Stud technology

The “Pull-out proof” connection
for rolling stock

The stud technology allows all power distribution configurations
and improves wiring secureness thanks to “Pull-out proof"
connection (stud+lug).
The HD terminal blocks provides a large scope of 1 and 2 studs
configurations with different types of washers and nuts
(Onduflex , Trep , Grover ).
®
®
®
The D type power blocks provide an alternative with specific
locking foot and rotative covers.
The RGW terminal blocks offer a combination of fast and
secured wiring, with captive nuts in a pivoting wing.

Reliable in harsh conditions
Continuous operation guaranteed for rolling stock
– Environmental tests: aging, corrosion, flammability, toxicity
(I2F2, V0, HL3 R22)
– Mechanical tests: vibration and shock.

6

Safety and protection
Secured wiring
– Captive wire connection: stud + ring lug
– Anti-vibration and anti-loosening equipments: self locking
nuts, spring washers.

More control in smaller space
High density wiring with compact design
– 2 studs version: up to 4 conductors per block
– Compact 1 stud version for 2 conductors.
