Railway applications, terminal blocks
Stud technology
Technologies presentation 170
Overview 172
1 stud
4 mm² HD4/9.F4 M4 stud with self locking nut + spring washers 176
HD4/9.F4.2 M4 stud with nut 177
HD4/10.F4.19 M4 stud with self locking nut + TREP washers 178
10 mm² HD10/12.F5.3 M5 stud with self locking nut + spring washers 179
HD10/12.F5 M5 stud with self locking nut + TREP washers 180
HD10/12.F5.1 M5 stud with 2 nuts + spring washers 181
HD10/12.F5.2 M5 stud with 2 brass nuts + spring washers 181
35 mm² HD35/16.F6.19 M6 stud with self locking nut + TREP washers 182
HD35/16.F6.19.1 M6 stud with 2 nuts + spring washers 183
70 mm² HD70/22.F8.31 M8 stud with self locking nut + TREP washers 184
HD70/22.F8.31.1 M8 stud with 2 nuts + spring washers 185
HD70/22.F8.31.2 M8 stud with 2 brass nuts + spring washers 185
120 mm² HD120/30.F10.31 M10 stud with self locking nut + TREP washers 186
HD120/30.F10.31.1 M10 stud with 2 nuts + spring washers 187
185 mm² HD185/36.F12.31.1 M12 stud with 2 nuts + spring washers 188
2 studs for TH35 & type 2 rails mounting
4 mm² HD4/9.FF4 M4 studs with self locking nut + spring washers 189
6 mm² HD6/13.FF4 M4 studs with self locking nut + spring washers 190
10 mm² HD10/12.FF5 M5 studs with self locking nut + TREP washers 191
16 mm² HD16/14.FF5.21.3 M5 studs with self locking nut + spring washers 192
HD16/14.FF5.20.3 M5 studs with self locking nut + spring washers 193
HD16/14.FF5.21 M5 studs with self locking nut + TREP washers 194
HD16/14.FF5.20 M5 studs with self locking nut + TREP washers 195
2 studs for TH35 & base mounting
35 mm² / 1 AWG D35/27.FF M6 studs with 2 nuts + spring washers 196
70 mm² / 000 AWG D70/32.FF M8 studs with 2 nuts + spring washers 197
6
120 mm² / 300 Kcmil D120/42.FF M10 studs with 2 nuts + spring washers 198
185 mm² / 500 Kcmil D185/55.FF M12 studs with 2 nuts + spring washers 199
300 mm² / 1000 Kcmil D300/55.FF M16 studs with 2 nuts + spring washers 200
2 studs with captive nuts
2.5 mm² / 14 AWG RGW2.5-V0 M3 studs feed-through with captive nuts 201
6 mm² / 10 AWG RGW6-V0 M4 studs feed-through with captive nuts 202
25 mm² / 4 AWG RGW25-M5-V0 M5 studs feed-through with captive nuts 203
25 mm² / 4 AWG RGW25-M6-V0 M6 studs feed-through with captive nuts 204
