MS116 manual motor starters
0.10 to 32 A – with thermal and electromagnetic protection

Description
MS116 is a compact and economic range for motor protection up to 15 kW (400 V) / 32 A in width
of 45 mm. Further features are the build-in disconnect function, temperature compensation, trip-free
mechanism and a rotary handle with a clear switch position indication. The manual motor starter is suitable
for three- and single phase applications. Auxiliary contacts, signaling contacts, undervoltage releases,
2 shunt trips, power in-feed blocks and locking devices for protection against unauthorized changes are
available as accessory. These are suitable throughout the MS116/MS132/MS165-range.
2CDC241010F0011 Ordering details

Setting
Rated
taneous short-
operational range Short-circuit Rated instan- Type Order code Weight
breaking
(1 pce)
MS116-16
power capacity I at circuit current
CS
400 V 400 V AC setting l i
AC-3
kW A kA A kg
0.03 2) 0.10 ... 0.16 50 2.00 1) MS116-0.16 1SAM250000R1001 0.225
0.06 0.16 ... 0.25 50 3.10 1) MS116-0.25 1SAM250000R1002 0.225
0.09 0.25 ... 0.40 50 5.00 1) MS116-0.4 1SAM250000R1003 0.225
0.18 0.40 ... 0.63 50 7.90 1) 1) MS116-0.63 1SAM250000R1004 0.225
2CDC241001F0011 0.25 0.63 ... 1.00 50 12.5 1) 1) MS116-1.0 1SAM250000R1005 0.225
1SAM250000R1006
20.0
0.55
MS116-1.6
1.00 ... 1.60 50
0.265
1SAM250000R1007
MS116-2.5
0.75
1.60 ... 2.50 50
31.3
0.265
1.50 2.50 ... 4.00 50 50.0 MS116-4.0 1SAM250000R1008 0.265
MS116-25 2.20 4.00 ... 6.30 50 78.8 MS116-6.3 1SAM250000R1009 0.265
4.00 6.30 ... 10.0 50 150 MS116-10 1SAM250000R1010 0.265
5.50 8.00 ... 12.0 25 180 MS116-12 1SAM250000R1012 0.265
7.50 10.0 ... 16.0 16 240 MS116-16 1SAM250000R1011 0.265
7.50 16.0 ... 20.0 10 300 MS116-20 1SAM250000R1013 0.310
11.0 20.0 ... 25.0 10 375 MS116-25 1SAM250000R1014 0.310
15.0 25.0 ... 32.0 10 480 MS116-32 1SAM250000R1015 0.310
0.03 2) 0.10 ... 0.16 50 2.00 1) 1) MS116-0.16-HKF1-11 1SAM250005R1001 0.240
2CDC241013F0011 0.06 0.16 ... 0.25 50 3.10 1) 1) MS116-0.25-HKF1-11 1SAM250005R1002 0.240
1SAM250005R1003
5.00
MS116-0.4-HKF1-11
0.25 ... 0.40 50
0.240
0.09
0.18
MS116-1.0-HKF1-11
0.63 ... 1.00 50
12.5
0.25 0.40 ... 0.63 50 7.90 1) MS116-0.63-HKF1-11 1SAM250005R1004 0.240
0.240
1SAM250005R1005
MS116-0.16-HKF1-11 0.55 1.00 ... 1.60 50 20.0 1) MS116-1.6-HKF1-11 1SAM250005R1006 0.280
0.75 1.60 ... 2.50 50 31.3 1) MS116-2.5-HKF1-11 1SAM250005R1007 0.280
1.50 2.50 ... 4.00 50 50.0 MS116-4.0-HKF1-11 1SAM250005R1008 0.280
2.20 4.00 ... 6.30 50 78.8 MS116-6.3-HKF1-11 1SAM250005R1009 0.280
4.00 6.30 ... 10.0 50 150 MS116-10.0-HKF1-11 1SAM250005R1010 0.280
5.50 8.00 ... 12.0 25 180 MS116-12.0-HKF1-11 1SAM250005R1012 0.280
7.50 10.0 ... 16.0 16 240 MS116-16.0-HKF1-11 1SAM250005R1011 0.280
7.50 16.0 ... 20.0 10 300 MS116-20-HKF1-11 1SAM250005R1013 0.326
2CDC241012F0011 15.0 25.0 ... 32.0 10 480 MS116-32-HKF1-11 1SAM250005R1015 0.326
0.326
MS116-25-HKF1-11
1SAM250005R1014
20.0 ... 25.0 10
11.0
375
The data is valid for products, produced after week 34, 2014.
1) Note: Manual motor starters should always be selected so that the actual motor current is within the setting range.
MS116-32-HKF1-11 2) 690 V
Main dimensions mm, inches
79.9 3.15"
80.1 3.15" 69.8 2.75"
1.5 0.06" 70 2.76" 1.5 0.06" 5.5 0.22" 43.3 1.7"
5.5 0.22" 43.5 1.71"
0.07" 0.07"
3.54" 1.7 2.95" 1.38" 1.77" 2.3" 3.85" 1.7 2.95" 1.38" 1.77"
90 1.1" 75 35 45 57.8 97.8 75 35 45 2.3"
27.5 1.1" 27.5 57.8
2CDC242002F0010 2CDC242001F0011
14 0.55" 14 0.55"
45 1.77" 14 0.55" 14 0.55"
45 1.77" 2CDC131062C0201a
MS116 ≤ 16 A & MS116-HKF1-11 ≤ 16 A MS116 ≥ 20 A & MS116-HKF1-11 ≥ 20 A
