MS132 manual motor starters
0.10 to 32 A – with thermal and electromagnetic protection

Description
MS132 is a compact and powerful range for motor protection up to 15 kW (400 V) / 32 A in width of 45 mm.
This type has also a clear and reliable indication of fault in a separate window in the event of short-circuit
tripping. Further features are the build-in disconnect function, temperature compensation, trip-free mechanism
and a rotary handle with a clear switch position indication. The manual motor starter is suitable for three- and
single phase applications. The handle is lockable to protect against unauthorized changes. Auxiliary contacts, 2
signaling contacts, undervoltage releases, shunt trips, power in-feed blocks are available as accessory. These
1SBC101232F0010 Ordering details
are suitable throughout the MS116/MS132/MS165-range.

Rated Setting Short-circuit Rated instan- Type Order code Weight
MS132-10 operational range breaking taneous short- (1 pce)
power capacity I at circuit current
CS
400 V 400 V AC setting l i
AC-3
kW A kA A kg
0.03 2) 0.10 … 0.16 100 2.00 1) MS132-0.16 1SAM350000R1001 0.215
0.06 0.16 … 0.25 100 3.10 1) MS132-0.25 1SAM350000R1002 0.215
0.09 0.25 … 0.40 100 5.00 1) MS132-0.4 1SAM350000R1003 0.215
0.18 0.40 … 0.63 100 7.90 1) 1) MS132-0.63 1SAM350000R1004 0.215
2CDC241001F0011 0.55 1.00 … 1.60 100 20.0 1) 1) MS132-1.6 1SAM350000R1006 0.265
MS132-1.0
0.215
1SAM350000R1005
12.5
0.63 … 1.00 100
0.25
31.3
1SAM350000R1007
0.75
0.265
MS132-2.5
1.60 … 2.50 100
MS132-6.3
78.8
0.265
1SAM350000R1009
2.20
4.00 … 6.30 100
MS132-32 1.50 2.50 … 4.00 100 50.0 MS132-4.0 1SAM350000R1008 0.265
4.00 6.30 … 10.0 100 150 MS132-10 1SAM350000R1010 0.265
5.50 8.00 … 12.0 100 180 MS132-12 1SAM350000R1012 0.310
7.50 10.0 … 16.0 100 240 MS132-16 1SAM350000R1011 0.310
7.50 16.0 … 20.0 100 300 MS132-20 1SAM350000R1013 0.310
11.0 20.0 … 25.0 50 375 MS132-25 1SAM350000R1014 0.310
15.0 25.0 … 32.0 25 480 MS132-32 1SAM350000R1015 0.310
0.03 2) 0.10 ... 0.16 100 2.00 1) 1) MS132-0.16-HKF1-11 1SAM350005R1001 0.231
2CDC241014F0011 0.06 0.16 ... 0.25 100 3.10 1) 1) MS132-0.25-HKF1-11 1SAM350005R1002 0.231
0.25 ... 0.40 100
0.09
1SAM350005R1003
MS132-0.4-HKF1-11
5.00
0.231
0.40 ... 0.63 100
MS132-0.63-HKF1-11
0.231
7.90
1SAM350005R1004
0.18
0.25 0.63 ... 1.00 100 12.5 1) MS132-1.0-HKF1-11 1SAM350005R1005 0.231
MS132-0.16-HKF1-11 0.55 1.00 ... 1.60 100 20.0 1) MS132-1.6-HKF1-11 1SAM350005R1006 0.281
0.75 1.60 ... 2.50 100 31.3 1) MS132-2.5-HKF1-11 1SAM350005R1007 0.281
1.50 2.50 ... 4.00 100 50.0 MS132-4.0-HKF1-11 1SAM350005R1008 0.281
2.20 4.00 ... 6.30 100 78.8 MS132-6.3-HKF1-11 1SAM350005R1009 0.281
4.00 6.30 ... 10.0 100 150 MS132-10.0-HKF1-11 1SAM350005R1010 0.281
5.50 8.00 ... 12.0 100 180 MS132-12.0-HKF1-11 1SAM350005R1012 0.326
7.50 10.0 ... 16.0 100 240 MS132-16.0-HKF1-11 1SAM350005R1011 0.326
7.50 16.0 ... 20.0 100 300 MS132-20-HKF1-11 1SAM350005R1013 0.326
2CDC241015F0011 15.0 25.0 ... 32.0 25 480 MS132-32-HKF1-11 1SAM350005R1015 0.326
20.0 ... 25.0 50
MS132-25-HKF1-11
1SAM350005R1014
375
11.0
0.326
1) Note: Manual motor starters should always be selected so that the actual motor current is within the setting range.
The data is valid for products, produced after week 34, 2014.
MS132-32-HKF1-11 2) 690 V
Main dimensions mm, inches
81.05 3.19"
81.25 3.2" 72.2 2.84"
72.4 2.85" 1.5 0.06" 5.5 0.22" 43.3 0.22"
1.5 0.06" 5.5 0.22" 43.5 1.71"
0.1"
0.1" 3.85" 1.7 2.95"
3.54" 1.7 2.95" 1.38" 1.77" 97.8 75 1.38" 35 1.77" 45
90 75 35 45"
2CDC242015F0009 2CDC242016F0009
14 0.55" 14 0.55" 14 0.55" 14 0.55"
45 1.77" 45 1.77"
MS132 ≤ 10 A MS132 ≥ 12 A 2CDC131062C0201a
