6/4 ABB CONTACTORS AND MOTOR PROTECTION

—
T16 thermal overload relays – 0.10 to 16.0 A

Ordering details

The T16 thermal overload relays are economic electromechanical protection devices for the main
circuit. They offer reliable protection for motors in the event of overload or phase failure.
The devices have trip class 10.
The thermal overload relays are three pole relays with bimetal tripping elements. The motor
current flows through the bimetal tripping elements and heats them directly and indirectly. In
case of an overload (over current), the bimetal elements bent as a result of the heating. This leads
2CDC231009F0013 to a release of the relay and a change of the contacts switching position (95-96 / 97-98).
• Manual or automatic reset selectable

• TEST and STOP function – Trip indication on the front
T16 • Phase loss sensitive acc. to IEC/EN 60947-4-1
• Temperature compensation
• Suitable for three- and single-phase applications
Setting range Short-circuit Trip class Type Order code Weight
protective device (1 pce)
A kg
Suitable for AS09...AS16, B6 and B7 all variants 1SAZ711201R1005 0.100
0.5 A, fuse type T
0.10 ... 0.13
T16-0.13
10
2CDC231025F0013 0.13 ... 0.17 1.0 A, fuse type T 10 T16-0.17 1SAZ711201R1008 0.100
06
1.0 A, fuse type T
T16-0.23
0.100
1SAZ711201R1009
0.17 ... 0.23
10
10
T16-0.31
0.100
1SAZ711201R1013
0.23 ... 0.31
1.0 A, fuse type T
T16 + DB16 0.31 ... 0.41 2.0 A, fuse type gG 10 T16-0.41 1SAZ711201R1014 0.100
0.41 ... 0.55 2.0 A, fuse type gG 10 T16-0.55 1SAZ711201R1017 0.100
0.55 ... 0.74 4.0 A, fuse type gG 10 T16-0.74 1SAZ711201R1021 0.100
0.74 ... 1.00 6.0 A, fuse type gG 10 T16-1.0 1SAZ711201R1023 0.100
1.00 ... 1.30 6.0 A, fuse type gG 10 T16-1.3 1SAZ711201R1025 0.100
1.30 ... 1.70 10.0 A, fuse type gG 10 T16-1.7 1SAZ711201R1028 0.100
1.70 ... 2.30 10.0 A, fuse type gG 10 T16-2.3 1SAZ711201R1031 0.100
1SFC151224F0002 2.30 ... 3.10 10.0 A, fuse type gG 10 T16-3.1 1SAZ711201R1033 0.100
3.10 ... 4.20
1SAZ711201R1035
T16-4.2
20.0 A, fuse type gG
0.100
10
4.20 ... 5.70
0.100
10
35.0 A, fuse type gG
T16-7.6
5.70 ... 7.60 20.0 A, fuse type gG 10 T16-5.7 1SAZ711201R1038 0.100
1SAZ711201R1040
KPR-101L 7.60 ... 10.0 35.0 A, fuse type gG 10 T16-10 1SAZ711201R1043 0.104
10.0 ... 13.0 40.0 A, fuse type gG 10 T16-13 1SAZ711201R1045 0.104
13.0 ... 16.0 40.0 A, fuse type gG 10 T16-16 1SAZ711201R1047 0.104
Ordering details accessories
Description Suitable for Type Order code Weight
(1 pce)
kg
2CDC231002F0011 Reset push button E16, EF, TF, T16, TA200 KPR-101L 1SFA616162R1014 0.027
1SAZ701901R0001
DB16
T16
Single mounting kit
0.032
DB16
8.6 0.34" 9.1 0.36"
1.2 0.05" 36.9 1.45" 2.4 0.09"
3.02"
76.7
2CDC232008F0008
9.1 0.36" 12.35 0.49" 35.6 1.4"
8.1 0.32" 14.4 0.57" 48.2 1.9"
45 1.77" 53.5 2.11"
T16 2CDC106036C0201
Main dimensions mm, inches
