Mounting feet - Shaft extensions

1SBC104030F0014 Mounting feet

Description

When the contactors are to be fitted on a back plate the mounting feets provide an increased clearence
behind the contactor for easier cabling.

Two pieces are required for one contactor.

4NMW1009/1039 Ordering details

7 4NMW1041 For R contactors Drilling for bar fixing Ø Fixing centres Type Order code Pkg Weight
for vertical wall qty (2 pce)
63 ... 170 mm mounting 4NMW1009 FPL7108201P0001
200, 260 4NMW1039 FPL7608201P0001 kg
400, 500, 550 6.2 mm 4NMW1041 FPL8308201P0001 2 0.060
8.2 2 0.060
12.5 85 / 100...110 2 0.320
85 / 100...110
110...120

1SBC104029F0014 Main dimensions mm ø 8.5

2 x ø 6.5

ø 6.2* 100 ... 110 ø 10.5* 110 ... 120
ø 8.2* 85 ø 12.5* 54
22 x 8.5
20 x 6.5

15 40

* 4 NMW 1009 : ø = 6.2 R0111D 22 50
* 4 NMW 1039 : ø = 8.2 * 4 NMW 1041 : ø = 12.5
R0112D

Shaft extensions

Description

For 3 or 4 pole reversing or changeover pairs built with two contactors of different ratings, vertically mounted
above one another. Fitting on the shaft of the contactor having the smaller frame size.

Ordering details Type Order code Pkg Weight

For R contactors qty (1 pce)

63 ... 170 kg
200 ... 420
400, 500, 550 - FPTN410111R0001 1 (1)
(1) On request.
- FPTN410111R0002 1 (1)

- FPTN410111R0003 1 (1)

1SBC104095S0201 - Rev. A

7/8 | ABB R contactors
