P. 123
Mechanical interlock units
Description
The VM mechanical interlock units are designed for the interlocking of two R contactors of the same rating.
The mounting between 2 contactors of a same rating doesn't affect their fixing centres or their overall dmen-
sions.
Ordering details
For R contactors type Rating Fixing Type Order code Pkg Weight
IOR, NOR , JOR, LOR and FOR center qty (1 pce)
mm VM21/24 FPL7101403R0001
IOR...-CC, IOR...-MT, NOR...-CC, 63 VM25 FPL7401404R0001 kg
NOR...-MT, LOR... 125 220 VM27 FPL8001401R0001
IOR...-CC, IOR...-MT, NOR...400, 200 260 VM15-SP FPL8301401R0002 1 0.140
LOR... 400 ... 500 320 1 0.180
520 1 0.260
1 0.500
1SBC388162F0302
1SBC104094S0201IOR…, LOR…800, NOR…800,800 ... 1000520VM16FPL8601401R00011 0.600
FOR…1000
VM IOR…-CC, IOR…-MT 800 … 1000 640 VM17/18 FPL8801401R0001 1 0.700
IOR..., LOR..., FOR... 1400, 1700, 2100 640
IOR…-CC, IOR…-MT 1400, 1700, 2100 680 VM19 FPL9001401R0001 1 0.800
Note: For special versions, please consult us: 7
- interlocking between contactors with N.O. + N.C. poles or with latching
- interlocking between 2 contactors of different ratings
- interlocking between 3 contactors.
ABB R contactors | 7/7
