Main poles

1SBC388134F0302NB Contacts sets for N.O. or N.C. main poles

Description

The contact sets include 1 fixed contact, 1 moving contact, 1 arcing horn (according to table below) and
screws.

The quantities needed are defined per ratings as follow:
–– 1 set per pole for R63….R800, R1000, R1400, R1700, R2100
–– 2 sets per pole for R1250, R1500, R2500, R3200, R3800
–– 3 sets per pole for R2000, R4500, R5100
–– 4 sets per pole for R3150
–– 5 sets per pole for R4000.

Ordering details Order code Pkg Weight
qty (1 pce)
For R contactors type
kg

Contact set with arcing horn

IOR, NOR, JOR, FOR 63, 85 FPTN410389R0001 1 set 0.050

125, 170 FPTN410389R0002 1 set 0.150

200, 260 FPTN410389R0003 1 set 0.250

315, 400 (1), 420 FPTN410389R0004 1 set 0.400
7 400 (2), 500, 550, 630
FPTN410389R0005 1 set 0.480

Contact set without arcing horn

LOR 85 FPTN410390R0001 1 set 0.040
FPTN410390R0002 1 set 0.090
170 FPTN410390R0003 1 set 0.180
FPTN410390R0004 1 set 0.250
260 FPTN410390R0005 1 set 0.470
FPTN410391R0001 1 set 0.520
420 FPTN410503R0001 1 set 0.520
FPTN410506R0001 1 set 0.830
400, 550

IOR, NOR, JOR, FOR, LOR 800, 1000, 1250, 1500, 2000, 3150, 4000

1400, 2500

1700, 2100, 3200, 3800, 4500, 5100

(1) For NOR and JOR types, N.C. poles.
(2) For IOR, NOR, JOR, N.O. poles.

Arcing horns for N.O. or N.C. main poles

Ordering details

1SBC104033F0014 For R contactors type Order code Pkg Weight
IOR, NOR, JOR, FOR qty (1 pce)

800, 1000, 1250, 1500, 2000, 3150, 4000 FPTN410446R0001 kg
1400, 2500 FPTN410446R0001
1700, 2100, 3200, 3800, 4500, 5100 FPTN410508R0001 1 0.200
1 0.200
1 0.280

1SBC104050S0201 - Rev. A

7/4 | ABB R contactors
