Main poles
1SBC104032F0014 Equipotential connections
Description
Equipotential connections must be ordered separately for ratings ≥ 800 A.
Ordering details Type Order code Pkg Weight
qty (1 pce)
For R contactors type NO poles FPTN410176R0006
IOR, NOR, JOR and FOR NC poles FPTN410176R0007 kg
800 ... 5100 1 0.500
800 ... 4000 1 0.530
Arc chutes
Description
De-ion arc chutes replace basic arc chutes except for 315 and 420 A ratings.
1SBC387943F0302 Ordering details Type Order code 7Pkg Weight
For R contactors type De-ion arc chute FPTN401938R0002 qty (1 pce)
IOR, NOR, JOR and FOR De-ion arc chute FPTN401939R0002 kg
De-ion arc chute FPTN401940R0002
63, 85 Basic arc chute FPTN401936R0002 1 0.470
125, 170 De-ion arc chute FPTN401941R0002 1 0.930
200, 260 De-ion arc chute FPTN410067R0002 1 1.360
315, 400 (1),420 De-ion arc chute FPTN410067R0002 1 1.300
400 (2), 500, 550 De-ion arc chute FPTN410507R0001 1 3.600
800, 1000, 1250, 1500, 2000, 3150, 4000 1 2.570
1400, 2500 1 2.570
1700, 2100, 3200, 3800, 4500, 5100 1 3.150
(1) For NOR and JOR types, N.C. poles.
(2) For IOR, NOR, JOR types, N.O. poles.
Pressure springs, insulated supports, complete poles and
other spare parts
Please contact your local sales organisation (order code for R contactor needed).
