LORR couplers
Power circuit up to 1000 V AC or 1500 V DC
AC operated

1SBC104043F0000 Description

LORR are used for controlling:

–– AC power circuits up to 1000 V AC

–– DC power circuits up to:
--1000 V DC for ratings 85…550 A
--1500 V DC for ratings 800…5100 A.

LORR550-20 They are not suitable for breaking on-load at voltages above 24 V AC or DC.

5 These contactors are designed with:
–– variable number of poles according to the application
5/8 | ABB R contactors –– control circuit: AC operated
–– 1 N.O. and 1 N.C. auxiliary contacts available, as standard.

Ordering details Number Rated control Auxiliary Type Order code Weight
contacts pkg
Conventional Rated of poles circuit voltage fitted (2) (1 pce)
thermal current operational voltage kg
lth (θ ≤ 40 °C) Uc 2.6
(1) 3
3.4
A V AC V DC (3) V 50/60 Hz 3.8
3.2
90 1000 1000 1 220...230 1 1 LORR85-10 FPL7235110R0006 4.1
2 1 1 LORR85-20 FPL7235210R0006 5
3 1 1 LORR85-30 FPL7235310R0006 5.9
4 1 1 LORR85-40 FPL7235410R0006 4.7
185 1000 1000 1 220...230 1 1 LORR170-10 FPL7535110R0006 5.9
2 1 1 LORR170-20 FPL7535210R0006 7.1
3 1 1 LORR170-30 FPL7535310R0006 8.3
4 1 1 LORR170-40 FPL7535410R0006 11.4
300 1000 1000 1 220...230 1 1 LORR260-10 FPL7835110R0006 14.7
2 1 1 LORR260-20 FPL7835210R0006 18
3 1 1 LORR260-30 FPL7835310R0006 21.3
4 1 1 LORR260-40 FPL7835410R0006 11.4
420 1000 1000 1 220...230 1 1 LORR400-10 FPL9435110R0006 14.7
2 1 1 LORR400-20 FPL9435210R0006 18
3 1 1 LORR400-30 FPL9435310R0006 21.3
4 1 1 LORR400-40 FPL9435410R0006 29
630 1000 1000 1 220...230 1 1 LORR550-10 FPL8435110R0006 34
2 1 1 LORR550-20 FPL8435210R0006 42
3 1 1 LORR550-30 FPL8435310R0006 54
4 1 1 LORR550-40 FPL8435410R0006 30
1100 1000 1000 1 220...230 1 1 LORR800-10 FPL8635110R0006 36
1500 2 1 1 LORR800-20 FPL8635210R0006 44
1500 3 1 1 LORR800-30 FPL8635310R0006 56
1500 4 1 1 LORR800-40 FPL8635410R0006 34
1400 1000 1000 1 220...230 1 1 LORR1400-10 FPL6135110R0006 42
1500 2 1 1 LORR1400-20 FPL6135210R0006 50
1500 3 1 1 LORR1400-30 FPL6135310R0006 66
1500 4 1 1 LORR1400-40 FPL6135410R0006 36
1700 1000 1000 1 220...230 1 1 LORR1700-10 FPL6235110R0006 44
1500 2 1 1 LORR1700-20 FPL6235210R0006 52
1500 3 1 1 LORR1700-30 FPL6235310R0006 68
1500 4 1 1 LORR1700-40 FPL6235410R0006 On
2100 1000 1000 1 220...230 1 1 LORR2100-10 FPL6335110R0006 request
1500 2 1 1 LORR2100-20 FPL6335210R0006
1500 3 1 1 LORR2100-30 FPL6335310R0006 On
1500 4 1 1 LORR2100-40 FPL6335410R0006 request
2500 1000 1000 1 220...230 1 1 LORR2500-10 FPL6735110R0006
1500 2 1 1 LORR2500-20 FPL6735210R0006 On
1500 3 1 1 LORR2500-30 FPL6735310R0006 request
1500 4 1 1 LORR2500-40 FPL6735410R0006
3200 1000 1000 1 220...230 1 1 LORR3200-10 FPL6535110R0006 On
1500 2 1 1 LORR3200-20 FPL6535210R0006 request
1500 3 1 1 LORR3200-30 FPL6535310R0006 On
1500 4 1 1 LORR3200-40 FPL6535001R0006 request
3800 1000 1000 1 220...230 1 1 LORR3800-10 FPL6635110R0006
1500 2 1 1 LORR3800-20 FPL6635210R0006
1500 3 1 1 LORR3800-30 FPL6635002R0006
1500 4 1 1 LORR3800-40 FPL6635003R0006
4500 1000 1000 1 220...230 1 1 LORR4500-10 FPL6835110R0006
1500 2 1 1 LORR4500-20 FPL6835210R0006 1SBC104075S0201 - Rev. A
1500 3 1 1 LORR4500-30 FPL6835001R0006
5100 1000 1000 1 220...230 1 1 LORR5100-10 FPL6935110R0006
1500 2 1 1 LORR5100-20 FPL6935001R0006

(1) Other control voltages see voltage code table.
(2) Other auxiliary contact arrangements, see auxiliary contact code table.
(3) Please consult us for power circuit above 1000 V AC or 1500 V DC.
