AM-CC-JORE2500 and
AMF-CC-JORE2500 alternator field discharge contactors
Technical data

Magnet system characteristics

Types Single tripping coil AM-CC-JORE2500-21 AM-CC-JORE2500-31

Double tripping coil AMF-CC-JORE2500-21 AMF-CC-JORE2500-31

Coil operating limits

acc. to IEC 60947-4-1 At θ ≤ 55 °C 0.85…1.1 x Uc

DC control voltage 24…220 V DC
950 W
Rated control circuit voltage Uc 265 W

Coil consumption Average pull-in value 950 W
265 W
Tripping

Operating time (average values for Uc)

Closing time 85 ms
50 ms
Opening time

Mounting characteristics Single tripping coil AM-CC-JORE2500-21 AM-CC-JORE2500-31 5

Types Double tripping coil AMF-CC-JORE2500-21 AMF-CC-JORE2500-31

Fixing by screws (not supplied) 4 x M12 4 x M12

Connecting characteristics

Types Single tripping coil AM-CC-JORE2500-21 AM-CC-JORE2500-31

Double tripping coil AMF-CC-JORE2500-21 AMF-CC-JORE2500-31

Connection capacity (min. ... max.)

Main conductors (poles) 150 mm
Terminal plates width -
8 x ø9 mm
Terminal screw (not supplied)

Drilling holes (without thread)

Auxiliary conductors

(built-in auxiliary terminals + coil terminals)

Rigid solid 1 or 2 x 1…2.5 mm²
1…2.5 mm²
Flexible with non insulated ferrule 1 or 2 x
1.5 Nm
Tightening torque 1.5 Nm

Coil terminals Screws and bolts
M4 with cable clamps
Built-in auxiliary terminals M4 with cable clamps

Screw terminals

Main terminals

Coil terminals

Built-in auxiliary terminals
