Railway current sensors NCS range
Electronic technology for infrastructure only

Designed to be integrated into every
situation

The NCS sensor is entirely symmetrical. Its square shape and
strategically positioned oblong holes make it easy to fasten
in a choice of 2 positions. As an accessory it comes with a
165 mm 125 mm side plate that can be fastened on either side of the sensor
3 giving complete fitting flexibility. It meets the standard design
of ABB current sensors. It can be fitted both horizontally and
vertically. This flexibility means that NCS sensors can be fitted in
any position and simplifies the work of integrators. Additionally
the pair of right angle brackets allows the NCS sensor to be
fitted to one or several bars at the same time.

100% electronic

The main advantage of the NCS range of sensors is that they are
designed using a brand-new solution: 100% electronic technology.
Unlike other currently available solutions such as shunts and CTs,
this approach means that these sensors are very compact.
Several patents were necessary to achieve this improvement.

Considerable energy savings

NCS sensors offer considerable savings in energy. Indeed only
a few watts are required to power the NCS sensor in contrast
to traditional sensors that require several hundred watts.
This reduction in wasted energy means there is no rise in tem-
Quality that goes beyond standards perature around the sensor.

ABB have been ISO 9001 certified since 1993 and our standard
NCS sensors bear the CE label in Europe. Environment-friendly
This ongoing striving after quality has always been the hallmark
of a company where excellence and safety are part of the ABB have long been concerned with the protection of the
culture, from design right through to production. environment, as proved by the ISO 14001 certification they received
This culture is the result of continuous research to make technical in 1998. This environmental approach is particularly noticeable in
progress and meet our customers' demands. the production of the NCS range in the reduction of the number of
components, in the use of a low-energy manufacturing procedure
The chief selling-point of NCS sensors is their quality. Compliance and the use of recyclable packing. The products in use are also
of their high-tech electronic design with standard EN 50155 is characterized by their reduced energy consumption.
proof of their ability to comply with the most detailed constraint Our NCST range is RoHS compliant.
as well as major demands. The fact that each individual sensor
is subjected to rigorous testing is proof of the importance ABB NCS Substation sensors have been designed to meet
attribute to quality. the substation standards EN 50123-1 and EN 50121-5.
NCS range sensors also meet the security standard EN 50124-1. 1SBC140042S0201
The NCS meets all of your requirements
