An answer adapted
to market requirements

Guaranteeing optimum reliability, the VD Railway voltage
detector meets the requirements for difficult environments and
is adaptable to the most demanding applications such as:
– rolling stock: main converters, auxiliary converters. Based
on the SNCF CF60-100 specification, the whole French
railway market imposes the presence of a voltage detector
within built redundancy, to meet the drastic requirements of
this sector.
– electronic power systems integrating capacitors banks:
3
backups, wind generators, variable speed drives,
electrolysis require voltage detectors of robust design
and offer high reliability.

A considered and measured integrated
design
100% electronic
Thanks to a 100% electronic technology, ABB has reduced
the size of the VD Railway voltage sensor to a minimum. At the forefront of technological innovation at ABB, the VD Railway
The ultra-compact dimensions allow for simplified installation. voltage detector is 100% electronic. Other than the assurance of
Additionally, its self-sufficiency in energy means that it can providing unbeatable performance, it has reduced dimensions:
work without an external power supply. smaller and more compact, it offers greater installation flexibility.
Its 100% electronic technology also provides it with an
excellent immunity to surrounding magnetic fields: a guarantee
for accurate detection of a given voltage.

Double lifetime to avoid taking any risks

The VD Railway voltage detector is a voltage detection sys-
tem with built in redundancy. It is equipped with two electronic
circuits each connected to a light emitting diode (LED). These
two parallel and independent systems guarantee a high level of
functioning and improve the reliability of the detector.

Quality that goes beyond standards
Environment-friendly
The new product complies with the standard EN 50155 (high
technology electronic design and testing) and EMC EN 50121-3-2 Reduction of the number of components, low energy manufac-
(electromagnetic compatibility: resistance to electromagnetic turing processes, use of recyclable packing, reduced energy
interference) and follows a very rigorous manufacturing process. consumption… The VD Railway voltage detector complies with
all the requirements of the ISO 14001 environmental standard,
Certified ISO 9001 and CE labeled, the VD Railway voltage in place at ABB since 1998.
detector complies with the most rigorous standards and
requirements.

The VD Railway voltage detector is the only product on the
market that complies with rolling stock security standards such
as: EN 50124-1 (electrical isolation), EN 50163 (standardized
voltage 1500 V DC).
1SBC140062S0201

Because your security is essential

ABB | 85
