PCGS wire and cable markers
Slide-in precut blank labels

1SNC700181F0000 Description

–– Blank marker card for thick wires,
–– To be inserted in RINGT209 holder,
–– Made of PVC.

2 Main technical data
PCGS209
Material
PVC Flammability Temperature range
V0 -40°C to +60°C -40°F to +140°F

Ordering details Nb. of Color Type Order code Pkg Weight
markers PCGS209 card (1 card) g
Dimensions per card HTP500-PL
White 1SNA235150R0500 40 10.00
mm in 60

PCGS
For RINGT holders
20 x 9.3 0.787 x 0.366

Marking system accessories 1SNA235704R0500 1 294.00

HTP500-PL
Support plate
Included in the HTP500-V2 kit

RINGT209 transparent marker holders
For PCGS markers

1SNC160100F0014 Description

–– Transparent tie-on marker holders profiled to allow thick tube identification,
–– Use with PCGS209 markers,
–– Made of PVC.

RINGT209 Main technical data Flammability Temperature range
V0 -50°C to +80°C -58°F to +176°F
Material
PVC

Ordering details Color Type Order code Pkg Weight
1SNA235142R2100 pce (1 pce) g
Dimensions
240 6.00
mm in

For thick tube mounting

RINGT209

Tie-on sealed transparent holder for PCGS markers

9.5 x 20 0.374 x 0.787 Transparent RINGT209

Use holders only with designated cable marker of the same or a shorter length.
Dimensions given apply to the labelling area.

1SNC160195S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
