HTP500 wires and cables markers
Selection guide

For evolutive identification

Marker holders + slide-in markers

2

Wire external diameter Marker holder length Marker holder Compatible marker
mm in mm in
RING122 WMTT 12
Slide-on cable marker holder RING182 WMTT 18
RING124 WMTT 12
Ø 1.5 ... 2.5 Ø 0.059 ... 0.098 12 0.472 RING184 WMTT 18
0.709 RING127 WMTT 12
18 0.472 RING187 WMTT 18
0.709 RING1210 WMTT 12
Ø 2 ... 4 Ø 0.079 ... 0.157 12 0.472 RING1810 WMTT 18
0.709
RING 18 0.472 SNAP152 WMTT 12
SNAP 0.709 SNAP232 WMTT 18
Ø 4 ... 7 Ø 0.157 ... 0.276 12 SNAP154 WMTT 12
SNAP234 WMTT 18
18 SNAP157 WMTT 12
SNAP237 WMTT 18
Ø 6 ... 10 Ø 0.236 ... 0.394 12 SNAP1510 WMTT 12
SNAP2310 WMTT 18
18

Clip-on cable marker holder

Ø 2 ... 3.5 Ø 0.079 ... 0.138 15 0.591
0.906
23 0.591
0.906
Ø 2.8 ... 5 Ø 0.11 ... 0.197 15 0.591
0.906
23 0.591
0.906
Ø 5 ... 8 Ø 0.197 ... 0.315 15

23

Ø 8 ... 10 Ø 0.315 ... 0.394 15

23

For identification of thick tubes

Tie-on markers / marker holders

RINGT23 Marker holder length Marker holder Compatible marker
mm in
23 23 RINGT23 WMTT 18
28 28 RINGT209 PCGS209

RINGT209
