LH, LH-R1 end stop label holders
For MCLH labels

1SNK160210F0014 Description

–– Easily identify your terminal blocks assembly with white or yellow labels,
–– Adjustable in height for best visibility,
–– Compatible with all SNK end stops.

Main technical data 2

Material Flammability Temperature range
Polyamide V0 -55°C to +110°C -67°F to +230°F

Ordering details

Spacing Dimensions Color Type Order code Pkg Weight
pce (1 pce) g
mm in mm in Dark Grey LH
Dark Grey LH-R1
For MCLH 8.8 x 30 0.35 x 1.18 1SNK900605R0000 50 0.60

LH
10 0.394

LH For MCLH-R1 1SNK900607R0000 50 1.10
LH-R1
LH-R1
19.5 0.768 17.9 x 35.65 0.70 x 1.40

Dimensions given apply to the labelling area.

Compatible end stops

BAM3 BAZ1 BAZH1 1SNC160201S0201
1SNK900001R0000 1SNK900002R0000 1SNK900102R0000

All the technical data for UL/CSA standard and dimensions in inches are in italic.
