MC terminal block markers
Blank markers for SNK series

1SNK160156F0014 Description

2 MC512 –– Blank marker card designed for high marking quality,
–– Dedicated to SNK series terminal block marking,
–– Excellent marking durability in the most severe environments,
–– Made of rigid polycarbonate.

Main technical data Flammability Temperature range
V0 -55°C to +110°C -67°F to +230°F
Material
Polycarbonate

Ordering details

Dimensions Maximum Nb. of Color Type Order code Pkg Weight
mm in printed digits markers card (1 card) g
per card
Hor. Vert.

SNK series terminal block markers

MC512

For 5.2 mm 0.205 in spacing terminal blocks and BAZ1 end stop

12 x 5 0.472 x 0.197 3 8 45 White MC512 1SNK140000R0000 22 9.00
1SNK140004R0000 22 9.00
Yellow MC512-YL
1SNK150000R0000 22 10.00
MC612 White MC612 1SNK150004R0000 22 10.00
Yellow MC612-YL
For 6 mm 0.236 in spacing terminal blocks 1SNK160000R0000 22 10.00
12 x 5.6 0.472 x 0.220 3 8 39 1SNK160004R0000 22 10.00

MC812

For 8 mm 0.315 in and larger spacing terminal blocks and BAM3 end stop

12 x 7.6 0.472 x 0.299 4 8 30 White MC812

Yellow MC812-YL

Marking System Accessories HTP500-PL2 1SNA235705R0600 1 291.00

HTP500-PL2
Support plate
Included in the HTP500-V2 kit

Mounting instruction 1SNC160190S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
