RC..TT terminal block markers
Blank markers for SNA and Solution series

1SNC160246F0014 Description

–– Blank marker card designed for high marking quality,
–– Excellent marking durability in the most severe environments,
–– Made of rigid polycarbonate.

RC510TT Main technical data 2

Material Flammability Temperature range
Polycarbonate V0 -50°C to +120°C -58°F to +248°F

Ordering details

Dimensions Maximum Nb. of Color Type Order code Pkg Weight
mm in printed digits markers card (1 card) g
per card
Hor. Vert. 22 12.00
22 12.00
For 5 mm 0.197 in terminal block spacing
22 12.00
R C 510 T T White RC510TT 1SNA231600R1500 22 12.00
Yellow RC510TT-YL 1SNA231700R1100
For 5 mm 0.197 in spacing terminal blocks 22 12.00
10 x 5 0.394 x 0.197 3 7 48 22 12.00

For 6 mm 0.236 in terminal block spacing 1 291.00

R C 610 T T White RC610TT 1SNA233600R1700
Yellow RC610TT-YL 1SNA233700R1300
For 6 mm 0.236 in spacing terminal blocks
10 x 6 0.394 x 0.236 3 7 39

For 8 mm 0.315 in terminal block spacing

R C 810 T T

For 8 mm 0.315 in and larger spacing terminal blocks and end stops from SNA series

10 x 8 0.394 x 0.315 4 7 30 White RC810TT 1SNA234600R1000

Yellow RC810TT-YL 1SNA234700R1400

Marking System Accessories HTP500-PL2 1SNA235705R0600

HTP500-PL2
Support plate
Included in the HTP500-V2 kit

Mounting instruction

1SNC160191S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
