HTP500 thermal transfer printer

Marking system

Description
– Performance,
– High volume and serial production,
– Dedicated for ABB terminal blocks.

Ordering details
HTP500-V2 KIT
Description Color Type Order code Pkg Weight
qty (1 pce) g
Thermal transfer printer KIT HTP500-V2 KIT 1SNA235700R1500 1
List of items included in the KIT :
1 HTP500-V2 Thermal transfer printer HTP500-V2
1 software CD HTS500
1 power supply cable HTP500-PW
1 USB cable HTP500-USB
1 support table HTP500-BAS
1 universal feeder for marker cards HTP500-FEED
HTP500-CLEAN 1 cleaning cassette HTP500-CLEAN
1 black ribbon cassette RIB-B
1 support plate for ABB terminal block markers HTP500-PL2 6
1 universal support plate for wire markers HTP500-PL

Feeders and support plates
Description Color Type Order code Pkg Weight
qty (1 pce) g
Universal feeder for marker cards HTP500-FEED 1SNA235703R0400 1
Support plate for ABB terminal block markers HTP500-PL2 1SNA235705R0600 1
Universal support plate for wire markers HTP500-PL 1SNA235704R0500 1

HTP500-FEED
Accessories
Description Color Type Order code Pkg Weight
qty (1 pce) g
Black ribbon cassette RIB-B 1SNA235710R0600 3
Red ribbon cassette for identification plates RIB-R 1SNA235711R2300 3
HTP500-PL2 and adhesive labels
Red ribbon cassette for terminal blocks RIB-RS 1SNA235718R0200 3
and wire markers
Cleaning cassette HTP500-CLEAN 1SNA235714R2600 1
Standard cleaning roll ø18 HTP500-ROLL 1SNA235715R2700 1
Printing head HTP500-PRINT 1SNA235716R2000 1
Dust cover for HTP500 and AMS 600 systems DUST COVER 1SNA360161R1500 1
Wooden box for HTP500-V2 KIT HTP500-WB 1SNA235717R2100 1
Software CD HTS500 1SNA235702R0300 1
Support table HTP500-BAS 1SNA235706R0700 1
Power supply cable HTP500-PW 1SNA235709R1200 1
RIB-B

1SNK160015S0201 - Rev. A

All the technical data for UL/CSA standard and dimensions in inches are in italic.
