Markers for components

Markers and marking systems

MG-TAR markers for components
1SNC160138F0014 Description
Identify your terminal blocks assembly with the precut blank label adapted to the LH label holders.

Ordering details
MG-TAR
Description Nb. of Nb. of Color Type Order code SW Pkg Weight
markers card by code
MG-TAR 8.5 0.335" per card package marker 1 marker g
For LH label holder
50
18
MG-TAR 45194
For LH-R1 label 33 50 White MG-TAR 45490 1SNB045490R8530 720 1650 0.371
1SNB045194R1735 711
900
0.628
30 1.18" holder
Main technical data
MG-TAR Material specifications Insulating material Rigid PVC
V0
Flammability
17 0.669 Ambient temperature NF F 16 101 -30 ... +80 °C -22 ... +176 °F
Service IEC 60068-2-1
min/max Storage -30 ... +80 °C -22 ... +176 °F
Installing +10 ... +40 °C +50 ... +104 °F
6 35 1.378"
MG-TAA markers for components
1SNC160139F0014 Description
Identify your terminal blocks assembly with the self adhesive label adapted to the LH label holders.

Ordering details
MG-TAA
Description Nb. of Nb. of Color Type Order code SW Pkg Weight
markers card by code
MG-TAA 8.5 0.335" per card package marker 1 marker g
33
White
For LH label holder
825
33 25 Yellow MG-TAA 49498 1SNB049498R8530 33 825 0.55
0.55
25
1SNB049448R8530 33
MG-TAA 49448
30 1.18" For LH-R1 label 18 25 White MG-TAA 49198 1SNB049198R1735 711 450 0.91
holder 18 25 Yellow MG-TAA 49148 1SNB049148R1735 711 450 0.91
Main technical data
MG-TAA Material specifications Insulating material Rigid PVC
17 0.669 Flammability V0
NF F 16 101
Ambient temperature Service IEC 60068-2-1 -30 ... +80 °C -22 ... +176 °F
min/max Storage -30 ... +80 °C -22 ... +176 °F
35 1.378" Installing +10 ... +40 °C +50 ... +104 °F

Marking system & accessories
Description Color Type Order code Pkg Weight
qty (1 pce) g
Thermal transfer printer Grey MG3 KIT 1SNB419001R0000 1 12600
1SNK160099S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
Technical data valid for copper conductors only.
