Thermistor motor protection relays
Ordering details

Description 2

The thermistor motor protection relays CM-MSx are used to control motors equipped with
PTC temperature sensors. The PTC temperature sensors are incorporated in the motor wind-
ings to measure the motor heating. This enables direct control and evaluation of various oper-
ating conditions. Depending on the products also ATEX approvals for use in hazardous areas
are availabe.
ABB also offers PTC temperature sensors C011 (according to DIN 44081) which are suitable
for embedding in motor windings.

Ordering details CM-MSx

Rated control Output Function Type Order code Price Weight
1 pce (1 pce)
supply
kg (lb)
voltage
0.11 (0.24)
2CDC 251 014 V0014 24 V AC 1 n/o Autoreset CM-MSE 1SVR550805R9300
110-130 V AC CM-MSE 1SVR550800R9300 0.11 (0.24)
220-240 V AC Autoreset, dynamic CM-MSE 1SVR550801R9300
interrupted wire detection, CM-MSS.11P 1SVR740720R1400 0.11 (0.24)
non-volatile fault storage, 0.119
CM-MSS.51S 24-240 V AC/DC 1 n/c, 1 n/o ATEX approval CM-MSS.11S 1SVR730720R1400 (0.263)
0.127
CM-MSS.12P 1SVR740700R0100 (0.280)
0.105
24 V AC/DC 1 c/o (SPDT) Autoreset CM-MSS.12S 1SVR730700R0100 (0.231)
0.113
110-130 V AC, 1 c/o (SPDT) Autoreset CM-MSS.13P 1SVR740700R2100 (0.249)
220-240 V AC CM-MSS.13S 1SVR730700R2100 0.147
(0.324)
24-240 V AC/DC 1 n/c, 1 n/o Autoreset, dynamic CM-MSS.21P 1SVR740722R1400 0.155
interrupted wire detection, CM-MSS.21S 1SVR730722R1400 (0.342)
non-volatile fault storage, CM-MSS.22P 1SVR740700R0200
short-circuit detection, CM-MSS.22S 1SVR730700R0200 0.118
ATEX approval (0.260)

24 V AC/DC 2 c/o (SPDT) Auto, manual or remote reset 0.126
(0.278)
110-130 V AC, 2 c/o (SPDT) Auto, manual or remote reset CM-MSS.23P 1SVR740700R2200
220-240 V AC CM-MSS.23S 1SVR730700R2200 0.121
(0.267)
24-240 V AC/DC 1 n/c, 1 n/o Auto, manual or remote reset, CM-MSS.31P 1SVR740712R1400 0.132
dynamic interrupted wire CM-MSS.31S 1SVR730712R1400 (0.291)
detection, non-volatile fault CM-MSS.32P 1SVR740712R0200 0.163
storage, short-circuit detection, (0.359)
ATEX approval 0.174
(0.384)
24 V AC/DC 2 c/o (SPDT) Auto, manual or remote CM-MSS.32S 1SVR730712R0200
reset, dynamic interrupted CM-MSS.33P 1SVR740712R2200 0.120
110-130 V AC, 2 c/o (SPDT) wire detection, short-circuit CM-MSS.33S 1SVR730712R2200 (0.265)
220-240 V AC detection, ATEX approval
0.128
2 c/o (SPDT) Auto, manual or remote reset, CM-MSS.41P 1SVR740712R1200 (0.282)
dynamic interrupted wire CM-MSS.41S 1SVR730712R1200
24-240 V AC/DC detection, non-volatile fault 0.120
storage, short-circuit detection, (0.265)
2x1 c/o or, ATEX approval 0.130
1x2 c/o (0.287)
Auto, manual or remote reset, CM-MSS.51P 1SVR740712R1300 0.162
dynamic interrupted wire CM-MSS.51S 1SVR730712R1300 (0.357)
detection, non-volatile fault 0.172
storage, short-circuit detection, (0.379)
accumulative evaluation,
ATEX approval 0.130
(0.287)

0.141
(0.311)

0.135
(0.298)

0.145
(0.320)
