CT-D range
Wiring notes, Dimensional drawings
Wiring notes for devices with control input 2CDC 252 102 F0b06 1
A parallel load to the control input is possible
dimensions in mm
L(+)
A1 Y1/B1
A2
N(-)
Dimensional drawings
0.69“ 58 2.28“ 0.69“ 58 2.28“
17,5 0.2“ 17,5 0.2“
5 43,4 1.71“ 5 43,4 1.71“
70 2.76“ 80 3.15“
45 1.77“ 45 1.77“
2CDC 252 131 F0b06 2CDC 252 130 F0b06
CT-D devices with 1 c/o contact or 2 n/o contacts CT-D devices with 2 c/o contacts
