CP-B range
Dimensional drawings
Dimensions in mm and inches
99 3.90‘‘
93 3.66‘‘
3
112 4.41‘‘ 2CDC 272 037 F0010
60 2.36‘‘ 119 4.69‘‘
120 4.72‘‘ 197 7.76‘‘
CP-B 24/3.0 193 7.60‘‘
84 3.31‘‘ 188 7.40‘‘ 2CDC 272 039 F0010
196 7.72‘‘
CP-B 24/20.0 213 8.39‘‘
170 6.69‘‘ 2CDC 272 038 F0010
163 6.42‘‘ 99 3.90‘‘
93 3.66‘‘
116 4.57‘‘ 138 5.43‘‘ 60 2.36‘‘ 112 4.41‘‘ 2CDC 272 036 F0010
146 5.75‘‘ 119 4.69‘‘
CP-B 24/10.0 147 5.79‘‘ CP-B EXT.2 120 4.72‘‘
