Electronic protection devices EPD24
Ordering details
3 2CDC 051 001 S0010 The protection devices EPD24 extend the ABB product range of Modular DIN rail components by
electronic overcurrent protection modules for selective protection of 24 V DC load circuits.
EPD24-TB-101-3A This protection is achieved by a combination of active electronic current limitation in the case of a
short circuit and an overload deactivation from 1.1 x In upwards.
If a fault occurs in a load circuit, the protection device EPD24 will detect this rapidly and reliably,
disable the power output transistor and hence interrupt the current flow in the defective circuit. The
maximum possible overcurrent is always limited to 1.3…1.8 times the selected rated current. An
activation of capacitive loads up to 20,000 μF is possible, deactivation only occurring in the case of
overloads or short circuits. Selective deactivation of the defective current circuit means undefined
error states and a complete system stop are prevented.
Features
– Selective load protection, one electronic tripping characteristic.
– Active current limitation for safe connection of capacitive loads up to 20,000 μF and on
overload/short circuit.
– Current ratings 0.5 A...12 A.
– Reliable overload disconnection with 1.1 x IN
– Manual ON/OFF button
– Clear status and failure indication through LED and integrated auxiliary contact.
– Integral fail-safe element adjusted to current rating.
– Width per unit only 12.5 mm.
– Rail mounting
– Ease of wiring through busbar LINE+ and 0 V as well as signal bars.
– UL- and CSA-approvals allow international use of the devices.
Ordering details Type Order code Price Pkg Weight
qty (1 pce)
Ratedcurrent IN bbn 40 16779 EAN EPD24-TB-101-0.5A 2CDE601101R2905
A EPD24-TB-101-1A 2CDE601101R2001 kg (lb)
0.5 829960 EPD24-TB-101-2A 2CDE601101R2002
1 829984 EPD24-TB-101-3A 2CDE601101R2003 4 0.065
2 830003 EPD24-TB-101-4A 2CDE601101R2004 (1.433)
3 830027 EPD24-TB-101-6A 2CDE601101R2006
4 830041 EPD24-TB-101-8A 2CDE601101R2008 4 0.065
6 830065 EPD24-TB-101-10A 2CDE601101R2010 (1.433)
8 830089 EPD24-TB-101-12A 2CDE601101R2012
10 830102 4 0.065
12 830126 (1.433)
4 0.065
(1.433)
4 0.065
(1.433)
4 0.065
(1.433)
4 0.065
(1.433)
4 0.065
(1.433)
4 0.065
(1.433)
Ordering details bbn 40 Type Order code Price Pkg Weight
Description qty (1 pce)
16779 EAN kg (lb)
Busbars for LINE+ and 0 V, 830140 EPD-BB500 2CDE605100R0500 10 0.2
grey insulation, length 500 mm 1) EPD-SB21 2CDE605200R0021 (0.441)
Signal Bars for aux. contacts, grey 830164 10 0.4
insulation, length 21 mm (0.882)
1) Max. load with one line entry Imax = 50 A (recommended: mid line entry)
Max. load with two line entries Imax = 63 A
