Electronic protection devices EPD24
Approvals, Safety instructions

Please note
The user must ensure that the cable cross sections of the relevant load circuit are suitable for the current rating of the EPD24
used. Automatic start-up of machinery after shut down must be prevented (Machinery Directive 98/37/EG and EN 60204-1).
In the event of a short circuit or overload the load circuit will be disconnected electronically by the EPD24.

3

Information on UL approvals/CSA approvals
UL1604
UL File # E 339238

CSA C22.2 No. 213 (Class I, Division 2)
CSA File # 2305929

Operating Temperature Code T5
– This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non-hazardous locations only
WARNING:
– Exposure to some chemicals may degrade the sealing properties of materials used in the following device: relay

Sealant Material:
– Generic Name: Modified diglycidyl ether of bisphenol A
– Supplier: Fine Polymers Corporation
– Type: Epi Fine 4616L-160PK
– Casing Material:
– Generic Name: Liquid Crystal Polymer
– Supplier: Sumitomo Chemical
– Type: E4008, E4009, or E6008

RECOMMENDATION:
– Periodically inspect the device named above for any degradation of properties and replace if degradation is found

WARNING – EXPLOSION HAZARD:
– Do not disconnect equipment unless power has been removed or the area is known to be non-hazardous
– Substitution of any components may impair suitability for Class I, Division 2

UL2367
Non-hazardous use - UL File # E 339236

UL 508
Non-hazardous use - UL File # E 149922

CSA C22.2 No. 14
CSA C22.2 No. 142 - CSA File # E 2305929

Class 2
Meets requirement for Class 2 current limitation (EPD24 ... -0,5 A/1 A/2 A/3 A)

3/79 ABB | Catalog Electronic Products and Relays 2015 | 2CDC 110 004 C0210
