Pluggable interface relays
Ordering details - CR-P range

Ordering details - CR-P range

Rated control Outputs Contact Type Order code Price Pkg Weight
supply voltage ratings (1 pce)

qty kg (lb)

2CDC 291 045 F0004 12 V DC CR-P012DC1 1SVR405600R4000
24 V DC CR-P024DC1 1SVR405600R1000
CR-P 48 V DC 1 c/o (SPDT) 250 V, 16 A CR-P048DC1 1SVR405600R6000 10 0.014
110 V DC 2 c/o (SPDT) 250 V, 8 A CR-P110DC1 1SVR405600R8000 (0.031)
5 24 V AC CR-P024AC1 1SVR405600R0000
48 V AC CR-P048AC1 1SVR405600R5000
110 V AC CR-P110AC1 1SVR405600R7000 10 0.014
120 V AC CR-P120AC1 1SVR405600R2000 (0.031)
230 V AC CR-P230AC1 1SVR405600R3000
CR-P012DC2 1SVR405601R4000
12 V DC CR-P024DC2 1SVR405601R1000
24 V DC CR-P048DC2 1SVR405601R6000
48 V DC CR-P110DC2 1SVR405601R8000
110 V DC CR-P024AC2 1SVR405601R0000
24 V AC CR-P048AC2 1SVR405601R5000
48 V AC CR-P110AC2 1SVR405601R7000
110 V AC CR-P120AC2 1SVR405601R2000
120 V AC CR-P230AC2 1SVR405601R3000
230 V AC

Ordering details - CR-P range with gold contacts

Rated control Outputs Contact Type Order code Price Pkg Weight
supply voltage ratings (1 pce)

qty kg (lb)

24 V DC 2 c/o (SPDT) 250 V, 8 A CR-P024DC2 1SVR405606R1000 10 0.014
24 V AC gold contact CR-P024AC2G 1SVR405606R0000 (0.031)
110 V AC CR-P110AC2G 1SVR405606R7000
230 V AC CR-P230AC2G 1SVR405606R3000

Ordering details - Accessories

2CDC 291 006 F0011 Version Connection Type Order code Price Pkg Weight
terminal (1 pce)

qty kg (lb)

CR-PLS Logical socket with screw CR-PLS 1SVR405650R0000 0.045
CR-PJ protective separation screw CR-PLSx 1SVR405650R0100 (0.099)
Logical socket spring CR-PLC 1SVR405650R0200
CR-PSS 1SVR405650R1000 0.043
CR-PH 1SVR405659R0000 (0.095)
CR-PJ 1SVR405658R5000 10
CR-PM 1SVR405658R0000 0.042
(0.093)

2CDC 291 004 F0007 Standard socket screw 0.038
(0.084)

Plastic holder for socket 0.002
Jumper bar for sockets with screw (0.004)
connection 10
Marker 0.018
(0.040)

10 0.0002
(0.0004)
