P. 337
Interface relays and optocouplers R600 range
Type designators
SERIES CODE NB OF RELAYS CONTACT TYPE NB OF CONTACTS PARTICULARITIES
PER RELAY
R600 screw type R/B Ǣ Ǣ Ǣ
R600 spring type R/B/R Ǣ Ǣ Ǣ Ǣ
1 012 None / A / R
Ǣ
12
Features DC 5
None Input voltage AC/DC
Description of contact types A Input voltage
0 1 Normally Closed 1 NC R RC circuit protection :
1 1 Normally Open 1 NO - Input protection against leakage current
2 1 Change Over or Single Pole Double Through
- Increases relay contacts life
2CDC 110 004 C0210 | Catalog Electronic Products and Relays 2015 | ABB 5/30
